MFP31 QUICK REFERENCE GUIDE

contact: support@blustream.co.uk | support@blustream.com.au

MFP31

Quick Reference Guide

Our MFP31 is a portable multi-format presentation switch, featuring HDMI, Mini

DisplayPort™ and USB-C inputs to a single HDMI output, with manual or auto

source selection. The MFP31 supports HDMI 2.0 18Gbps specification including

pass-through of all formats of HDR and HDMI audio. The MFP31 is an ideal product

for your boardroom or huddle-space application.

Introduction

FEATURES:

• Features 1 x HDMI 2.0, 1 x USB-C and 1 x Mini DisplayPort™ input which can be switched to a single HDMI output

• Supports HDMI 2.0 18Gbps specification including HDR

• Supports resolutions up to 4K UHD 60Hz 4:4:4

• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD

Master Audio transmission

• Supports Mini DisplayPort™ up to 4K UHD 60Hz 4:4:4, DP1.2

• Supports USB Type C up to 4K UHD 60Hz 4:4:4, DP1.2

• Supports both manual and automatic source selection

• HDCP 2.2 compliant

MFP31 QUICK REFERENCE GUIDE

www.blustream.com.au | www.blustream.co.uk

Front Panel Description

1 USB-C input - connect to a USB-C source device using a cable capable of carrying video

2 HDMI 2.0 input - connect to a HDMI source device

3 Mini DisplayPort™ input - connect to a Mini DisplayPort™ source device

4 Power / Upgrade port - micro-USB - connect to USB power supply, or PC for firmware upgrade

5 HDMI 2.0 output - connect to display device

Rear Panel Description

4 5

Cable Requirements

It is important to carefully consider the cabling requirements for the Blustream MFP31 within your installation.

Distances that video and audio signals can travel will vary depending on the quality and specifications of the cable

chosen. It is recommended to use 18Gbps compliant cabling when using the MFP31 to pass UHD video content.

Please Note: charging cables supplied with most UBC-C phones, tablets and laptops are not capable of passing video

or audio signals. A cable that is capable of carrying video and audio must be specified. Keep cable distances to a

minimum to avoid signal loss, degradation, or handshaking issues.

1 2 3

Produktspecifikationer

Varumärke:	Blustream
Kategori:	Router
Modell:	MFP31
Videolägen som stöds:	1080p, 2160p
Antal HDMI-portar:	2
Certifiering:	FC, CE, RoHS
HDCP:	Ja
HDMI-version:	2.0
Färgdjup:	8 bit
Bandbredd:	18 Gbit/s
HDCP-version:	2.2
Antal HDMI-utgångar:	1
Produktens färg:	Grå
HD-typ:	4K Ultra HD
Temperatur vid drift:	0 - 40 ° C
Temperaturintervall (förvaring):	-20 - 60 ° C
Extern strömadapter:	Ja
Video porttyp:	HDMI
Strömkabel ingår:	Ja
Max uppdateringsfrekvens:	60 hz
Typ av USB-port:	USB Type-C
AC-adapter, nätspänning:	5 V
AC-adapter, maxbelastning:	1 A
HDMI-in:	1
Antal Mini Displayportar:	1
