RX18G QUICK REFERENCE GUIDE
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk
RX18G
Quick Reference Guide
01
The RX18G receiver is an industry leading uncompressed, unconverted HDMI 2.0 4K
60Hz 4:4:4 HDCP 2.3/2.2 solution utilising the latest in HDBaseT™ technology.
The RX18G supports uncompressed distribution of the latest HDR resolutions
including HDR10/10+ and Dolby Vision resulting in the ultimate in picture quality for
your critical viewing areas.
The RX18G supports bi-directional IR, RS-232 and PoC up to lengths of 100m over a
single CAT6A cable while also providing enhanced features including ARC via HDMI
or Optical (S/PDIF), and 1Gb Ethernet pass through.
Introduction
FEATURES:
• Advanced HDBaseT™ spec 3.0 technology oering distribution of video and audio over a single CAT6A cable
• Supports uncompressed HDMI2.0 18Gbps 4K 60Hz 4:4:4 specification including HDR
• Extends HDMI 1080p video up to 150m (HDBaseT™ long-reach mode)
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports ARC (Audio Return Channel) from connected display via HDMI or Optical digital inputs (when used with
compatible Blustream matrix)
• Bi-directional 1Gb Ethernet pass through when used with compatible Blustream matrix solution
• Supports all known HDMI audio formats including Dolby Atmos, Dolby TrueHD, Dolby Digital Plus and DTS-HD
Master Audio transmission
• Bi-directional RS-232 pass-through
• Supports bi-directional IR pass-through from compatible Blustream matrix
• Supports PoC (Power over Cable) from compatible Blustream matrix
• HDCP 2.3 support
• Recommended receiver to be used with Blustream HMX88-18G and HMX44-18G matrix
24V 1.25AETHERNETHDBT INRS-232IR INIR OUTHDMI OUTOPT OUTL/R OUT
TXRX
RX18G
OPT IN
LRM
ONOF
FO
NOFFCTRLFW
RS-232ARC
Produktspecifikationer
| Varumärke: | Blustream |
| Kategori: | audio/video-omvandlare |
| Modell: | RX18G |
