Sida 1/2

Instruction

Package Contents:

Thanks for choosing BOYA!

The BOYA BY-BMM400 is an omnidirectional conference microphone

with speaker, it is specially designed for video-shooting and phone

call conference.

Includes all necessaries cables, BY-BMM400 can work with

smartphones, tablets, PC and MP3 player and more. With portable

and compact design and the included carry case, you can take

BY-BMM400 with you nearly anywhere you go and turn easily any

room into a conference facility at any anytime and anywhere.

Features 12mm(0.5”) omnidirectional microphone, it is capable of

capturing sound in a 2m(6.6’) radius, with 360-degree voice

coverage. It’s the ideal choice for video conferencing because it can

simultaneously pickup all voices within the eective range.

Integrated built-in amplier and built-in volume gain control button

design, it greatly helps smartphones, tablets, PC to deliver louder

sound during phone call/ video conference, make sure everyone

could hear the contents from phone call/ video conference, and at

the same time,controls the output sound level very conveniently

and exibly under any occasions.

Features:

Product Introduction:

1. ON/OFF switch

2. Volume +

3. Volume -

4. Mute button

5. USB Type-C port

6. Line in

7. Headphone monitoring jack

8. 3.5mm TRRS connect cable

9. USB Type-C connect cable

10. USB Type-C to USB-A connect cable

Set up for Windows

Set up for Apple System

Important

Maintenance

Note:

1. Connect the microphone to the computer with the supplied

charge cable.

2. Select the microphone as the default device and click Start

Menu Control Panel Sounds and Audio Devices.→ →

- Select BY-BMM400 and click OK.

① Connect the BOYA BY-BMM400 to Type-C port on your computer.

② → →Choose Apple Icon System Preferences Sound Icon

Attach the microphone to Smartphone or tablet.

How to use?

Attach the microphone to computer or laptop.

1. Connect 3.5mm TRRS to TRRS output cable into your smartphone.

Also, the microphone is compatible with iOS devices with

lightning port by using the 3.5mm TRRS to lightning audio

adapter (not inclued).

2. Open the audio-only or video recording app and start recording.

3. When nishing, plug the audio monitoring jack and playback the

previous audio you recorded.

When using 3.5mm TRRS connect cable, it requires self power by

BY-BMM400's built-in lithium battery.

When using this cable, the power is supplied by Windows and

Mac Computers.

When using this cable, the power is supplied by Type-C devices.

- Select BY-BMM400 as sound output.

- If you do not intend to use the conference microphone for a long

period, please remove the cable from it.

- Do not touch the microphone while recording, as this will cause

noise to be recorded.

- Do not let the microphone close to high-voltage equipment or to

devices that emit strong electromagnetic elds, Otherwise, it may

cause the noise to be recorded.

- Do not use or leave the microphone in hot or humid places.

- Do not operate the device with wet hands or feet.

- Clean the equipment only in the way described in the instructions

for use.

1. It is a great solution for canceling low-frequency noise, placing

the mic in a quiet environment. Please don’t put the device on

the place where approach toelectricappliances such as air

conditions, computers and fans. Or the rumble and mechanical

voice may be recorded.

2. Please set the speaker volume at an appropriate level to avoid the

eect of distortion when the volume at a high level.

3. Some devices are not supported by the microphone, because of

its insucient power supply or incompatible system version.

Note:

When connecting to Android Type-C devices, please notice that the

BY-BMM400 works only with OTG functions devices.

- Select BY-BMM400 as sound input.

3. When the BY-BMM400 is connected to a Windows computer for

the rst time, the computer will show “Found New Hardware wizard,”

follow the instructions on screen to complete installing drivers for

the BOYA BY-BMM400. The above operation may need to be repeated

when connecting to a new computer or another port on the same

computer.

- Select BY-BMM400 and click OK.

- BY-BMM400 microphone

- 3.5mm TRRS audio output cable

- USB Type-C to USB-A cable

- USB Type-C to USB Type-C cable

- User manual

- Warranty card

Instruction Manual

BY-BMM400

Conference microphone speaker

- Compatible with smartphones, tablets, PC and more.

- Ideal for video-shooting and phone call conference

- Omni-directional polar pattern

- Excellent sound quality

- Portable and compact design

- Integrated microphone and amplier

- Pick up sound at 2m(6.6’) radius, with 360-degree coverage

- 3.5mm headphone monitoring

- Volume gain control available with blue LED indicator

- Mute function

Specications

Transducer：

Polar Pattern：

Frequency Response:

Output Power:

Power Requirements:

Plug:

Charging Time:

Built-in battery life:

Coverage Range:

Cable Length:

Size:

Weight:

Condenser

Omnidirectional

40-15,000Hz

2.5W

Built-in lithium battery or DC 5V/500mA

3.5mm TRRS audio interface

USB Type-C audio interface

USB-A audio interface

Approx. 2.5h

Approx 4.5h

2m (6.6ft) radius

1.2m (3.9ft)

120x120x33 mm (4.7x4.7x1.3'')

220g (7.8 oz)

电容式

全向型

40-15,000Hz

2.5W

内置锂电池或直流电 5V/500mA

3.5mmTRRS音频孔

Type-C接口

USB接口

约 2.5h

约 4.5h

2m 半径以内

1.2m

120x120x33 mm

220g

麦克风类型

拾音模式

频率响应

输出功率

供电方式

接口

充电时长

续航时间

拾音范围

尺寸

重量

3.5mm TRRS connect cable

USB Type-C connect cable

3.5mm TRRS (Female)

to Lightning (Male) Audio

Adapter(Not included)

iOS

USB Type-C to USB-A

connect cable

3.5mm TRRS 音频输出线

USB Type-C转Type-C

音频转接线

TRRS转Lightning

音频转接线

(本产品不包含)

iOS

USB Type-C转USB-A

音频转接线

产品清单

如何使用？

特点：参数：

麦克风连接电脑的操作步骤

苹果电脑设置教程

Windows电脑设置教程

麦克风连接手机或平板的操作步骤

产品结构

感谢您选择BOYA！

全向型会议麦克风

1.请使用3.5mm TRRS到TRRS音频输出线，到您的智能手机。

麦克风也同事兼用Lightning端口iOS设备，需要额外购买一条

3.5mm的TRRS转Lightning音频转接线 (本产品不包含)。

2.打开音频或视频录制app，开始录制。

3.录制结束后。将耳机插入监听孔，可进行音频的回放监听。

1. 选择合适的转接线，

连接麦克风和电脑。

2. 选择麦克风作为默认设备，

点击开始菜单→控制面板

→硬件和声音。

3. 当BY-BMM400第一次连接Windows计算机时，电脑会显示“发现新硬件向

导”按照指示说明完成驱动安装程序。

若连接新计算机或同一设备的其他端口，需重复上述操作。

① 选择Type-C转Type-C转接线线

② 点击左上角苹果标志→系统偏好

设置→声音

- 选择BY-BMM400为声音输入路径。

- 选择BY-BMM400为声音输出路径。

- 兼容智能手机、平板电脑、

个人电脑等。

- 电话会议，个人办公，网络教学

- 全向型拾音模式

- 传输稳定音质

- 便携小巧设计

- 内置麦克风和扬声器

- 360度全方位覆盖，2米拾音

半径范围，

- 3.5mm耳机监听口

- 音量控制键，LED电源指示灯

- 一键静音功能

- 在“播放”栏中，选择“BY-BMM400”

并点击“确认”。

- 在“录制”栏中，选择“BY-BMM400”

并点击“确认”。

博雅BY-BMM400是一款全向型会议麦克风(配有扬声器)，适用于电话会议，

个人办公等场景。

配备所有必需的音频转接线，BY-BMM400可支持智能手机，平板电脑，PC，

MP3播放器等设备。

便携小巧设计和收纳盒，BY-BMM400可随时随地进行办公。

直径12mm全向型会议麦克风，是视频会议的理想选择，360度全方位覆盖，

实现2米半径范围内的全向收音。



内置扬声器和音量按键,传输清晰饱满的音质，智能手机，平板电脑，个人电脑

都能顺利接入电话/视频会议。

• BY-BMM400麦克风

• 3.5mm TRRS 音频输出线

• USB Type-C转USB-A音频转接线

• USB Type-C转Type-C音频转接线

• 说明书

• 保修卡

1. 电源键

2. 音量增加键

3. 音量降低键

4. 静音按键

5. USB Type-C接口

6. 线性输入

7. 耳机监听孔

8. 3.5mm TRRS 音频输出线

9. USB Type-C转Type-C音频转接线

支持Type-C外接设备供电

10. USB Type-C转USB-A音频转接线

支持Windows, Mac电脑外接设备

供电（带USB-A接口）



www.boya-mic.com

SHENZHEN JIAYZ PHOTO INDUSTRIAL., LTD.

The BOYA logo is a trademark which is registered and owned by

Shenzhen Jiayz Photo Industrial., Ltd.

COPY RIGHT 2010-2020

TEL: 400 6131096

Email: sales@boya-mic.com

www.boya-mic.com / www.jiayz.com

深圳市长丰影像器材有限公司

地址:深圳市观澜街道章阁大富路智能终端产业园A16栋

Produktspecifikationer

Varumärke:	BOYA
Kategori:	mikrofon
Modell:	BY-BMM400
Bredd:	120 mm
Djup:	120 mm
Höjd:	33 mm
Laddningstid:	150 min
Batterikapacitet:	500 mAh
Inbyggda högtalare:	Ja
Antal inbyggda högtalare:	1
Volymkontroll:	Knappar
Gränssnitt:	USB/3,5 mm
Modell:	Konferensmikrofon
USB-anslutning:	USB Type-C
Kompatibla produkter:	Compatible with smartphones, tablets, PC and more.
Driftspänning:	5 V
Mikrofonfrekvens:	40 - 15000 hz
Batterityp:	Inbyggt batteri
Kabellängd:	1.2 m
Produktens färg:	Svart
Kontrolltyp:	Knappar
Mikrofonvikt:	220 g
Kabel inkluderad:	AUX, USB Type-C, USB Type-C to USB Type-A
Anslutningsteknologi:	Kabel
Monteringssätt:	Bord
På / av-knapp:	Ja
Strömkälla:	Batteri/DC
USB-port:	Ja
Externa anslutningar:	USB Type-C port; Line in; Headphone monitoring jack
Mikrofondämpning:	Ja
Drifttid för batteri:	4.5 h
Förpackningarnas innehåll:	BY-BMM400 microphone; 3.5mm TRRS audio output cable; USB Type-C to USB-A cable; USB Type-C to USB Type-C cable; User manual; Warranty card
Uttag för mikrofon/linje in:	Ja
Aux-In:	Ja
Mikrofon, riktning:	Rundtagande
Talspole typ:	Kondensator
Upptagningsområde för mikrofon:	2 m
