Sida 1/2
EM-362-EB
NECK WORN MICROPHONE
INSTRUCTION MANUAL
3. GENERAL DESCRIPTION
4. FEATURES
5. NOMENCLATURE AND FUNCTIONS
TOA's EM-362-EB is necklace clip microphone using high quality condenser microphone that be designed exclusive for
leader- player in mosque ( imam ) or other applications. This product is equipped with an optional power that is selectable
between battery or phantom power. Easy for adjustment microphone position to mouth for fine voice.
p#ZQSFTTJOHUIFCVUUPOUIFNJDSPQIPOFDBOCFUVSOPOPSPGG
p.JDSPQIPOFPQFSBUJPOCZTFMFDUJOHUIFCBUUFSZQIBOUPNTXJUDIPOCBUUFSZDBTF
p
Use two pieces batteries size “ AAA ”.
1. SAFETY PRECAUTION
#FGPSFJOTUBMMBUJPOPSVTFCFTVSFUPDBSFGVMMZSFBEBOE
follow all the precautionary instructions in this
section
to
ensure long, trouble-free use of your equipment
.
WARNING
WARNING
Be sure to act on the instructions as safety precaution
to prevent bodily injury and property damage.
Use the appropriate battery. Pay attention with the
batteries polarity when insert the batteries to unit.
"WPJEEJSFDUMZUPTVOMJHIUIJHIUFNQFSBUVSFPS
high humidity when come to storage of batter-
ies.
If the unit is not in used for more than 10 days.
3FNPWFBMMCBUUFSJFTUPQSFWFOUCBUUFSZMFBL-
age.
p
p
-
%POPUFYQPTFUIFVOJUUPSBJOPSBOFOWJSPONFOUXIFSFJUNBZCFTQMBTIFECZXBUFSPSPUIFSMJRVJEIJHI
temperature and high humidity.
%POPUPQFOUIFDPWFSUPNPEJGJDBUJPOPGVOJU'PSTFSWJDFDPOUBDUUIFOFBSFTU50"EFBMFS
%POPUESPQUIFVOJUUPIBSEPCKFDUBOEVTFESZDMPUIUPDMFBOUIFVOJU%POPUVTFHBTPMJOFUIJOOFSFUD
2. SAFETY MAINTENANCE
p
p
p
-
OPEN
1
2. Microphone
Close-talk type cardioid electret condenser micro-
phone. It have the high sensitivities and wide range
frequencies.
1. Wire Hanger
Using this on neck as a hook to microphone. the
hook made from strong material and can be streched
according to size of neck.
3. LED Ring
Light blue when the microphone is turned on and it
will turn off when microphone in off mode.
4. Flexible Shaft
Adjust the flexible shaft to microphone positioning
optimum performance.
5. Microphone ON/OFF Button
Press this key to turn on or off microphone.
6. Microphone Clip
6TJOHUIFDMJQPOUIFDMPUITIJSUFUDUPNBLFUIF
unit stable.
7. Cable Clip
Hook the clip to make the cable doesn’t interfere
VTFSOPUFBTJMZUPXBMLPOPSTBUPO
8. Batteries Compartment
Place the AAA batteries ( 2 pcs ).
9. Selector Switch
Selecting this switch to use battery or phantom as the
power supply for this unit.
10. Phone Plug
Direct connect balanced phone jack to input of ampli-
fier.
[ Front ]
9
2
3
4
5
6
7
8
10
133-04-00059-00
7. CONNECTION
8. OPERATION
9. USING THE SWITCH SELECTOR MODE
Step 1. Set the amplifier's microphone volume control to the minimum position.
Step 2. Plug the phone jack of microphone unit to the amplifier’s microphone input.
After announcement is completed, press the microphone ON/OFF button and microphone turn off.
Selector switch have 2 modes. There are battery mode and phantom power mode. If using battery as power input, select
the switch to battery position and if using phantom power as power input, select to phantom power position.
URL: http://www.toa.eu
6.2. Battery Insertion
6. BATTERY
6.1. Life Span
Application and use battery be assumed 1 hour/day and unit
can use until 6.7 months until 9.3 months according to brand
and type of batteries.
Step 1. Open the battery cover. Insert the battery according to battery polarity
(see the right picture )
Step 2. Put back the battery cover to product
Step 1. Use the necklace hanger to the neck, adjust the flexible shaft to first position ( see the top right picture). Hook
the both of clip to cloth, shirt, etc on your body.
Press the microphone ON/OFF button. The LEDs on unit will blue light and turning on the microphone.
Step 2.
Keep your mouth 5 – 10 cm away from the microphone and speak normally for the best possible sound repro-
duction. Adjust the microphone orientation for the best position by turning its flexible shaft. If distance of mouth
is too near, it cause voice distortion. Adjust the microphone by pulling away or lowering it. Because the high
sensitivity’s microphone.
Step 3.
Note : Be sure to press the ON/OFF button after announcement completion. Failure to do this, shortening the battery
life. Be sure to turn off the phantom power on other equipment if use chime microphone for durability of unit.
10. SPECIFICATION
Polar Pattern Cardioid
Rated Impedance 600 ohm, Balanced
Frequency Response Mic 60 Hz ~ 20 kHz
Output Connector
1/4 “ Balanced L Plug, 200 mm
Power Source
3V DC ( 2 x "AAA" batteries ) or Phantom power ( 9 ~ 52 V )
Cable Length
Flexible Shaft : Copper Alloy, Black, Paint, Shield tube
Battery Case Unit, Switch Unit, Mic Unit : ABS Resin, Black,
Weight
190 g ( exclude batteries )
7 m
Finish
0 °C to +40 °C (32 °F to 104 °F)
Wire Hanger : Steel wire shield rubber, Black, Paint
Dimensions 260 mm ( h ) x 135 mm ( w ) [10.24” x 5.31”)
Microphone Element Electret Condenser
Rated Sensitivity -35 ± 3 dB ( 1kHz 0 dB = 1 V/Pa )
Operating Temperature
Note: The design and specifications are subject without notice for improvement.
Distance Mic
to mouth
± 5 -10 cm
