Sida 1/19

TS-E17mm f/4L TS-E17mm f/4L

TS-E24mm f/3.5L II TS-E24mm f/3.5L II

Instructions

EENNGG

00-7587H1JEFSKFOR.qxd10.2.164:10PMページ2

COPY

ENG-1

Canon’s TS-E lenses are tilt-shift lenses

designed for EOS cameras. The tilt-shift

mechanism enables photographers to control

the depth of field and the area photographed

and to correct image distortion, making it

possible to take sophisticated pictures that

cannot be shot using a conventional lens.

● To ensure that you make the most of the TS-E lens

functionality, it is recommended that you shoot in the

following conditions.

• Use an EOS camera with 100% viewfinder visibility

(EOS-1, EOS-1D or EOS-1Ds series) and use the

laser matte with grid focusing screen Ec-D

• Use Live View

• Use a tripod

● On EOS cameras with a built-in flash, some partial

restrictions may apply to the shift and rotation

functions.

Features

1. Aspherical and UD lens elements result in

outstanding image delineation.

2. SWC (Subwavelength Structure Coating)

dramatically reduces ghosting and flare

caused by light entering at an acute angle.

3. The lens can be tilted up to ±6.5° (for TS-

E17mm f/4L) or ±8.5° (for TS-E24mm f/3.5L

II), and shifted up to ±12mm.

4. The tilt and shift functions can be used singly

or in combination. The tilt and shift can switch

from right angle to parallel using the TS

rotation feature.

5. The lens can be rotated to change the tilt or

shift direction.

6. A truly round aperture hole results in a nicer

background blur.

Thank you for purchasing a Canon product.

02-7587_ENG 10.2.10 3:48 PM Page 1

COPY

ENG-2

a Safety Precautions

●

Do not look at the sun or a bright light source

through the lens or camera. Doing so could result in

loss of vision. Looking at the sun directly through the

lens is especially hazardous.

●

Whether it is attached to the camera or not, do not

leave the lens under the sun without the lens cap

attached. This is to prevent the lens from concentrating

the sun’s rays, which could cause a fire.

●

To mount/detach the lens, always move the tilt and

shift scales to

“0”

. Fingers may get caught, or the

camera may be damaged.

●

When you tilt or shift the lens, sharp portions of the

tilt or shift mechanism are exposed and care should

be taken to avoid touching these portions.

●

Do not operate the shift function while operating the

rotation function. You may be injured by having your

fingers caught.

Handling Cautions

● If the lens is taken from a cold environment into a

warm one, condensation may develop on the lens

surface and internal parts. To prevent condensation

in this case, first put the lens into an airtight plastic bag

before taking it from a cold to warm environment. Then

take out the lens after it has warmed gradually. Do the

same when taking the lens from a warm environment

into a cold one.

● Do not leave the lens in excessive heat such as in a

car in direct sunlight. High temperatures can cause

the lens to malfunction.

02-7587_ENG 10.2.10 3:48 PM Page 2

COPY

Produktspecifikationer

Varumärke:	Canon
Kategori:	Lins
Modell:	TS-E 24mm f/3.5L II
Vikt:	780 g
Diameter:	88.5 mm
Fast brännvidd:	24 mm
Förstoring:	0.34 x
Filterstorlek:	82 mm
Linstyp:	Tilt/shift-objektiv
Produktens färg:	Svart
Produktlängd:	106.9 mm
Minsta bländarnummer:	3.5
Justering av fokus:	Manuell
Närmsta fokusavstånd:	0.21 m
Objektiv-struktur (element/grupper):	16/11
Antal diafragmablad:	8
Objektivets betraktningsvinkel, diagonal:	84 °
