■ Please read this manual and the enclosed safety materials carefully!
■ Fasten the manual near the garage door after installation.
■ The door WILL NOT CLOSE unless the Protector System
®
is connected and
properly aligned.
■ Periodic checks of the garage door opener are required to ensure safe operation.
■ The model number label is located on the left side panel of your garage door
opener.
■ This garage door opener is compatible with MyQ
®
and Security+ 2.0
®
accessories.
■ DO NOT install on a one-piece door if using devices or features providing
unattended close. Unattended devices and features are to be used ONLY
with sectional doors.
CONTENTS
Preparation. . . . . . . . . . . . . . . .2-5
Assembly . . . . . . . . . . . . . . . . .6-9
Installation . . . . . . . . . . . . . . 10-27
Adjustments . . . . . . . . . . . . . 28-30
Battery Backup. . . . . . . . . . . . . . 31
MyQ
®
Smartphone Control
Get Connected . . . . . . . . . . . . . . 32
Operation . . . . . . . . . . . . . . . 33-37
Maintenance . . . . . . . . . . . . . . . 38
Troubleshooting. . . . . . . . . . . 39-40
Accessories. . . . . . . . . . . . . . . . 41
Warranty. . . . . . . . . . . . . . . . . . 42
Repair Parts . . . . . . . . . . . . . 43-44
1-1/4 hps
*
Belt Drive
Garage Door Opener with
MyQ
®
Smartphone Control
and Battery Backup
The Chamberlain Group, Inc.
845 Larch Avenue
Elmhurst, Illinois 60126-1196
www.chamberlain.com
www.mychamberlain.com
Models
• WD1000WF
• HD950WF
• LW9000WF
FOR RESIDENTIAL USE ONLY
* Horsepower similar (hps) designates that this garage
door opener system meets Chamberlain’s pulling force
specification for a 1-1/4 horsepower garage door opener.
Write down the MyQ
®
serial number
located on the garage door opener:
2
Safety Symbol and Signal Word Review
This garage door opener hasbeen designed and tested to offer safe service provided itis installed,
operated, maintained and tested in strictaccordance with the instructionsand warnings contained in
this manual.
When you see these Safety Symbols and Signal Words on the following pages,they will alertyou to the
possibility ofserious injury or death if you do notcomply with the warnings that accompany them. The
hazard may come from something mechanical or from electric shock.Read the warningscarefully.
Mechanical
Electrical
When you see thisSignal Word on the following pages,it will alert you to the possibility ofdamage to
your garage door and/or the garage door opener if you do notcomply with the cautionary statements
that accompany it. Read them carefully.
Unattended Operation
The Timer-to-Close (TTC) feature, the MyQ
®
Smartphone Control app, and MyQ
®
Garage Door and
Gate Monitor are examples ofunattended close and are to be used ONLY with sectional doors.Any
device or feature that allowsthe door to close without being in the line ofsight of the door is considered
unattended close.The Timer-to-Close (TTC) feature, the MyQ
®
Smartphone Control, and anyother
MyQ
®
devices are to be used ONLY with sectional doors.
Check the Door
To prevent possible SERIOUSINJURYor DEATH:
l ALWAYS call a trained door systems technician if garage door binds,sticks,or isout of balance.
An unbalanced garage door may NOT reverse when required.
l NEVER try to loosen,move or adjust garage door,door springs, cables,pulleys,brackets or
their hardware, ALLof which are under EXTREME tension.
l Disable ALLlocks and remove ALLropesconnected to garage door BEFORE installation and
operating garage door opener to avoid entanglement.
l DO NOT install on a one-piece door ifusing devices or features providing unattended close.
Unattended devices and featuresare to be used ONLY with sectional doors.
To prevent damage to garage door and opener:
l ALWAYS disable locksBEFORE installing and operating the opener.
l ONLY operate garage door opener at 120V, 60Hz to avoid malfunction and damage.
Before you begin:
1. Disable locks and remove anyropesconnected to the garage door.
2. Lift the door halfway up. Release the door. Ifbalanced, it should stay in
place, supported entirely by its springs.
3. Raise and lower the door to checkfor binding or sticking.If your door
binds, sticks, or is out of balance, call a trained door systems
technician.
4. Check the seal on the bottom of the door. Anygap between the floor
and the bottom ofthe door mustnotexceed 1/4 inch (6 mm).
Otherwise,the safety reversal system may notwork properly.
5. The opener should be installed above the center of the door. Ifthere is
a torsion spring or center bearing plate in the way of the header
bracket, it may be installed within 4feet (1.2 m) to the left or rightof the
door center.See page 11.
Torsion
Spring
Extension
Spring
OR
Preparation
