USER MANUAL

VGA +R/L Audio to HDMI Converter

Model No.: CCN-VH101

Cable and Connectivity Company

VGA to HDMI Converter

Dear customer

Thank you for purchasing this product. For optimum performance and safety,

please read these instructions carefully before connecting, operating or

adjusting this product. Please keep this manual for future reference.

1.0 INTRODUCTION

This kind of the Converter is a VGA video converter. It converts VGA input into

HDMI and allows PC users to enjoy their larger image on TV. The conversion is

along with the R/L audio.

It offers solutions for digital entertainment center, HDTV retail and show site,

HDTV, STB, DVD and Projector factory, noise space and security concerns,

data center control, information distribution, conference room presentation,

school and corporate training environments.

1.1 FEATURES

This HDMI converter has many features that enable it to perform in a superior

manner. Among those features you will find:

 Easy to Use: Install in seconds, no need of setting.

 Conversion: It could convert PC’s VGA video and R/L audio into complete

HDMI.

 Supports highest video resolution 1280x1024.

 Supports 165MHz/1.65Gbps per channel (6.75Gbps all channel)

bandwidth.

 Supports 8bit per channel (24bit all channel) deep color.

2.0 SPECIFICATIONS

Signal Inputs/Output

Input Video Signal

0.5-1.0 volts p-p

Input DDC Signal

5 volts p-p (TTL)

Output Video

HDMI 1.2a

VGA Resolution

640x480 60Hz 75Hz

800x600 60Hz 75Hz

1024x768 60Hz 75Hz

1280x720 60Hz 75Hz

1280x768 60Hz 75Hz

1280x960 60Hz 75Hz

1280x1024 60Hz 75Hz

Operating Frequency

VGA to HDMI Converter

Vertical Frequency Range

50/60Hz

Video Amplifier Bandwidth 1.65Gpbs/165MHz

Mechanical

Size(W-H-D) 88mmW x 25.5mmH x 68mmD

Weight(Net)

0.68kgs

Warranty

Limited Warranty

2 Years Parts and Labor

Environmental

Operating Temperature

0  to +70

Operating Humidity 10% to 85 % RH (no condensation)

Storage Temperature

-10 to +80

Storage Humidity 5% to 95 % RH (no condensation)

Power Requirement

External Power Supply

5V DC@2A

Power consumption (Max)

Regulatory Approvals

Converter Unit

FCC,CE,

Power Supply

CE,FCC

Accessories Adapter

AC Power Adapter US standard, UK standard and so

User Manual

Note: Specifications are subject to change without notice.

3.0 PACKAGE CONTENTS

Before attempting to use this unit, please check the packaging and make sure

the following items are contained in the shipping carton:

 Main unit.

 5V DC Power Supply

 User's Manual

4.0 PANEL DESCRIPTIONS

Please study the panel drawings below and become familiar with the signal

input(s), output(s) and power requirements.

Produktspecifikationer

Varumärke:	Comprehensive
Kategori:	Inte kategoriserad
Modell:	CCN-VH101
Vikt:	2268 g
Bredd:	89 mm
Djup:	68 mm
Höjd:	29 mm
Videolägen som stöds:	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Maximal videoupplösning:	1920 x 1080 pixlar
Värdgränssnitt:	VGA + 2 x RCA
Spänning:	5 V
Produktens färg:	Svart
Extern strömadapter:	Ja
USB-ström:	Nej
Utgränssnittet:	HDMI
Driftström:	2 A
