INSTRUCTION MANUAL

GAS HOB

Model: CPCG601X

Contents

 Important Information

 Description of Hob

 Operation

 Maintenance and cleaning

 Troubleshooting

 Instruction for installer

 Technical data

 Important safety requirements

 Installation

 Conversion form NG to LPG or from LPG to NG

Please read this instruction manual before using the appliance!

Important Information

You MUST read these warnings carefully before installing or using the hob.

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a

hazard.

This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person

responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance

Installation

● Prior to installation, ensure that the local distribution conditions (nature of the gas and gas pressure) and the adjustment of the

appliance are compatible.

● It shall be installed and connected in accordance with current installation regulations. Particular attention shall be given to the

relevant requirements regarding ventilation.

● This appliance must be installed and serviced by a competent person

● This appliance shall be installed in accordance with the regulations in force and only used in a well ventilated space.

● Remove all packaging before using the hob

● Ensure that the gas and electrical supply complies with the type stated on the rating label

● Do not attempt to modify the hob in any way.

Child Safety

● This hob is designed to be operated by adults. Do not allow children to play near or with the hob.

● The hob gets hot when it is in use.

● Children should be kept away until it has cooled.

● Children can also injure themselves by pulling pans or pots off the hob.

During Use

● This hob is intended for domestic cooking only. It is not designed for commercial or industrial purposes.

● When in use a gas cooking appliance will produce heat and moisture in the room in which it has been installed. Ensure there is a

continuous air supply, keeping air vents in good condition or installing a cooker hood with a venting hose.

● When using the hob for a long period of time, the ventilation should be improved, by opening a window or increasing the extractor

speed.

● Do not use hob if it is in contact with water. Do not operate the hob with wet hands.

● Ensure the control knobs are in the closed position when not in use.

● When using other electrical appliances, ensure the cable does not come into contact with the hot surfaces of the cooking appliance.

● Unstable or misshapen pans should not be used on the hob as unstable pans can cause an accident by tipping or spillage.

● Never leave the hob unattended when cooking with oil and fats.

● Never use plastic or aluminum foil dishes on the hob.

● Perishable food, plastic items and aerosols may be affected by heat and should not be stored above or below the hob unit.

Service

● The hob should only be repaired or serviced by an authorized Service Engineer and only genuine approved spare parts should be

used.

Environmental Information

Produktspecifikationer

Varumärke:	Corberó
Kategori:	Ugn
Modell:	CPCG 601 X
Enhetsplacering:	Vrijstaand
Färg på produkten:	Blauw
Dörrgångjärn:	Rechts
Inbyggd display:	Nej
Timer:	Ja
Bredd:	455 mm
Djup:	520 mm
Höjd:	550 mm
Dörrfärg:	Rood
Ljudnivå:	38 dB
Energie-efficiëntieklasse:	F
Årlig-energiförbrukning:	99 kWu
Dörröppningsriktning utbytbar:	Nee
Kylskåpets nettokapacitet:	45 l
Antal gasbrännare:	4
Lägsta drifttemperatur:	10 °C
Maximal temperatur (drift):	38 °C
Klimaatklasse:	SN-ST
Bulleremissionsklass:	C
Ramfärg:	Svart
Energieffektivitetsskala:	A tot G
Infällda handtag:	Nee
Produktens färg:	Svart
Kontrolltyp:	Rotations-
Apparatens placering:	Inbyggd
Installationsfack, bredd:	553 mm
Installationsfack, djup:	473 mm
Barnsäkert:	Ja
Typ av spishäll:	Gas
Antal brännare / zoner matlagning:	4
Kokzon 3, form:	Rund
Diameter på platta/tillagningsyta 1:	92 mm
Placering av platta/tillagningsyta 4:	Höger fram
Typ av platta/tillagningsyta 4:	Sjudning
Typ av platta/tillagningsyta 3:	Vanlig
Kokzon 1, form:	Rund
Placering av platta/tillagningsyta 3:	Höger bak
Kokzon 2, form:	Rund
Strömförsörjning till platta/tillagningsyta 3:	gas
Diameter på platta/tillagningsyta 4:	75 mm
Typ av platta/tillagningsyta 1:	Vanlig
Placering av platta/tillagningsyta 2:	Främre till vänster
Diameter på platta/tillagningsyta 2:	118 mm
Diameter på platta/tillagningsyta 3:	92 mm
Strömförsörjning till platta/tillagningsyta 4:	Elektrisk
Strömförsörjning till platta/tillagningsyta 2:	gas
Typ av platta/tillagningsyta 2:	Stor
Kokzon 4, form:	Rund
Strömförsörjning till platta/tillagningsyta 1:	gas
Placering av platta/tillagningsyta 1:	Vänster bak
Manöverplats:	Övre höger
Effekt på platta/tillagningsyta 1:	1500 W
Effekt på platta/tillagningsyta 2:	3300 W
Effekt på platta/tillagningsyta 3:	1500 W
Effekt på platta/tillagningsyta 4:	1000 W
Typ av ytskikt:	Emaljerad
Lätt att rengöra:	Ja
Anslutningseffekt (elektrisk):	- W
Anslutningseffekt (gas):	- W
Ram formulär:	Direkt
Antal kokzoner som kan användas samtidigt:	4
Gastyp:	Gasol (LPG)
