Sida 1/2
ASSEMBLY DRAWING
A
D
C
E
F
G
FEATURES
部件图示 , 部件圖示
产品特点 , 產品特點
B
DEFENSOR S
L
English
PushBack advanced lumbar support system
preserves lower back health.
Magnetic memory foam neck pillow.
High-density molding foam.
4D adjustable armrest with luxurious velvet
fabric cover.
Leather-like fabric upholstery.
•
•
•
•
•
Português
O sistema de suporte lombar PushBack
preserva a saúde da região lombar.
Almofada para pescoço de espuma com
memória magnética.
Espuma de moldagem de alta densidade.
Apoio de braço ajustável em 4D com capa
de tecido de veludo luxuoso.
Estofado com tecido imitando couro.
•
•
•
•
•
Система поддержи поясницы PushBack
сохраняет здоровье нижней части спины.
Магнитная подушка для шеи с эффектом
памяти.
Высокоплотная формованная пена.
4D регулируемые подлокотники с
роскошной бархатной обивкой.
Обивка, имитирующая кожу.
Русский
•
•
•
•
•
Français
•
•
•
•
•
Le système de soutien lombaire PushBack préserve
la santé du bas du dos.
Oreiller de nuque en mousse à mémoire magnétique.
Mousse moulée haute densité.
Accoudoir réglable en 4D avec revêtement en tissu
velours luxueux.
Revêtement en tissu ressemblant à du cuir.
Deutsch
•
•
•
•
•
Das PushBack-Lendenstützsystem bewahrt die
Gesundheit des unteren Rückens.
Magnetisches Memory-Foam-Nackenpolster.
Hochdichte Formgedächtnis-Schaum.
4D verstellbare Armlehnen mit luxuriösem
Samtstoffbezug.
Polsterung aus Leder-ähnlichem Stoff.
日本語
PushBack 腰部サポートシステムは、下背部の健康を守ります。
マグ ネットメモリーフォームの首 枕。
高密度成形フォーム。
4D調整可能なアームレスト、豪華なベルベット生地カバー。
レザー風の生地で仕上げられたシート。
•
•
•
•
•
简 中
PushBack 腰部支撑系统保护下背部健康
磁吸式记忆颈枕
高密度成型泡棉
4D可调式扶手附带天鹅绒布扶手套
仿皮革布质椅面
•
•
•
•
•
繁 中
PushBack 腰部支撐系統保護下背部健康
磁吸式記憶頸枕
高密度成型泡棉
4D可調式扶手附帶天鵝絨布扶手套
仿皮革布質椅面
•
•
•
•
•
한국어
PushBack 요추 지지 시스템은 허리 건강을 보호합니다.
자석 메모리 폼 목베개.
고밀도 몰딩 폼.
4D 조정 가능한 팔걸이, 고급 벨벳 원단 커버.
가죽과 유사한 직물 덮개.
•
•
•
•
•
H
I
J
K
Español
•
•
•
•
•
El sistema de soporte lumbar PushBack
preserva la salud de la zona lumbar.
Almohada para el cuello de espuma con
memoria magnética.
Espuma moldeada de alta densidad.
Reposa brazos ajustable en 4D con cubierta
de tela de terciopelo lujosa.
Tapizado con tela de aspecto cuero.
Українська мова
•
•
•
•
•
Система підтримки попереку PushBack зберігає
здоров'я нижньої частини спини.
Подушка для шиї з магнітною меморі-фоамою.
Високощільна формуюча піна.
4D регульовані підлокітники з розкішною
велюровою тканиною.
Оббивка з матеріалу, що нагадує шкіру.
Seat Height Lift
椅座高度调整
椅座高度調整
Angle Adjustor
椅背倾仰调整
椅背傾仰調整
Tilting
搖椅功能
Magnetic Neck Pillow Cushion
磁吸式记忆颈枕
磁吸式記憶頸枕
PushBack 腰部支撑系统
PushBack 腰部支撐系統
PushBack Lumbar Support System
L
请抬起拨片解锁
并推靠腰部支撑
請抬起撥片解鎖
並推靠腰部支撐
如何收回腰部支撑
如何收回腰部支撐
How to retract
the lumbar support
Please lift the paddle to
unlock and push against
the lumbar support.
4D Folding Armrest
4D 可调式折迭扶手 / 4D 可調式摺疊扶手
上下升降
Up-Down
前后滑动, 前後滑動
Front-Back
旋转, 旋轉
Rotate
Step 3
位置到定点后轻提扶手面喀哒，即为锁定。
位置到定點後輕提扶手面喀噠，即為鎖定。
CLICK
Position to the designated point, then gently
lift the handle and click to lock in place.
Hold the switch upwards and simultaneously
press the armrest down all the way. At this
point, the armrest unlocks and can be rotated
backward.
3 position lock.
向上按住开关，并同时按压扶手面下压
到底，此时扶手解开锁定可向后转动。
向上按住開關，並同時按壓扶手面下壓
到底，此時扶手解開鎖定可向後轉動。
Step 1
Step 2
请务必确保扶手为锁定状态，以避免手臂支撑扶手时，
扶手向后倾倒。
請務必確保扶手為鎖定狀態，以避免手臂支撐扶手時，
扶手向後傾倒。
Please make sure that the armrest is locked in place to
prevent it from tilting backward when your arm is resting
on it.
3段角度位置锁定
3段角度位置鎖定
+
90°
115°
135°
9
0
°
~
1
5
5
°
UnlockUnlock
LockLock
弹力调整, 彈力調整
TightTight
Loose
With Armrest Cover
附扶手布套
With Armrest Cover
附扶手布套
UnlockUnlock
LockLock
LEGAL NOTICES
This manual was created by Compucase Enterprise and may not be completely or partially copied, passed on,
distributed or stored without written consent by Compucase Enterprise.
COUGAR® is a registered brand of Compucase Enterprise Other product and company names mentioned in
this documentation may be brands or trademarks of their respective owners.
Compucase Enterprise reserves the right to make changes concerning the contents of the manual and the
technical data of the product without previous announcement.
WARNING
Do not make fast or violent movements when the chair is in movement.
Do not touch any of the chair’s adjustment controls to prevent affecting its stability and causing a
potentially dangerous fall.
When reclining the chair to its full extent, set the related control level in lock position and keep both feet
on the ground, as well as abstain from any violent, rough or strong movement which could cause the chair
to tip over.
Keep in mind that this chair is designed only for sitting and reclining, and that it should be used only for
those uses.
Do not sit on the edge of the chair or the arm rests.
Do not place the chair in a location in which it is likely to be subjected to prolongated sunlight exposure.
The product’s colors might fade when exposed to sunlight.
Do not use abrasive products or scrub energetically when cleaning. Please stick to gentle products
suitable for delicate materials.
All parts should be checked monthly to confirm their integrity and to make sure that the screws are not
loose.
If any part of the product is or appears to be damaged, missing or loose, please contact the local
distributor and do not use the product.
To adjust the chair height, gently pull the lever up. Do not use excessive force to pull the lever.
Please wear protective gloves when assembling the chair. It is your own responsibility to use appropriate
protection to prevent any physical damage.
When rocking the chair, using it in any other way or adjusting the height, inclination, position or balance
of the chair or any of its components, please:Pay attention to your hand’s position and keep it away from
spaces in which it could get caught or be injured.
DISCLAIMERS
COUGAR products should not be used as critical components in life support devices.
COUGAR is not liable for any damage of life and limb or damage or loss of property caused by or during
COUGAR products’ use as or with medical equipment, military equipment, traffic equipment and disaster
prevention systems.
COUGAR's warranty liability is limited to repair or replacement. The decision on whether to repair or replace
belongs exclusively to COUGAR .
COUGAR is, to the extent not prohibited by law, not liable for any damages; expenses; lost data, revenues,
savings or profits; or any incidental or consequential damages happened while the use of a defective product
from COUGAR or due to its use.
WARRANTY AGREEMENT
If the product has defects in material or manufacture, COUGAR will provide product repair and
replacement service within the warranty period.
Our warranty service is based on the date of the invoice or warranty card.
GLOBAL WARRANTY POLICY
WARRANTY PERIODS OF COUGAR GAMING DEVICES
This warranty gives you specific legal rights. You may also have other rights
granted under local law. These rights may var y.
CONDITIONS WHERE FREE MAINTENANCE IS NOT PROVIDED
Any fault or damage caused by natural disasters (including storm, fire, flood, thunder, earthquake, etc).
Any fault or damage caused by accidental factors and man-made reasons (including hit, scrape, crash,
moving, compression, stain, corrosion, riot, misuse, malicious damage, etc).
Use in an improper operating environment (including high temperature, high humidity, water inflow, etc).
Inability to provide the product warranty card, purchase receipt or invoice to prove the product is still within
the warranty period and the shipping date of the product is out of warranty.
The warranty card has been altered or its number is hard to identify.
The warranty period has expired.
Any fault or damage caused by non-compliance with regulations stated on the user manual or improper,
rough and careless treatment.
Any fault or damage caused by use of parts not certified by COUGAR original manufacturer.
The problem is caused by improper repair or adjustment by the buyer or any manufacturer without
authorization from COUGAR.
The product is not acquired from an authorized distributor of the company or is acquired from illicit sources.
Paper carton, instruction and other accessories are not warranted.
год и месяц изготовления продукции ук азаны в серийном номере продукта.
(существует 2 способа определения даты изготовления, оба спос оба описаны ниже)
После S/N: первые две цифры означают год, вторые две – месяц изготовления.
Например, S/N: H 000001 означает, что товар был произведен в феврале 2017 года.1702
После S/N: если указаны буквы, то две буквы представляют цифры из таблицы ниже,
и означают год, последующие две цифры – месяц изготовления.
Например, S/N: D REVI000001 означает, что товар был произведен в феврале 2017 года.AG02
●
Например, AG = 17 = 2017 год
ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ
A B C E F H I JD G
1 3 4 5 6 8 9 02 7
A
B
Product : COUGAR DEFENSOR S Gaming Chair
Warranty : Please refer to our official website.
(https: //cougargaming.com/us/support /warranty/ )
保固政策 : 中国地区购买，请参考中国地区官方网站。
(http://cougargaming.com.cn/support/warranty/)
全球保固条款 , 全球保固條款
詳細保固條件
請掃描Qr Code
ASSEMBLING INSTRUCTION
2
ACCESSORY KIT
DISTRIBUTOR
A
B
Maximum stationary weight capacity 150kg. Please do not place any body or
object above 150kg on this chair. From spaces in which it could get caught or be
injured.
MANUFACTURER CONTACT
1
9
5 mm
1
x4
M8×25mm
3
x12
M8×20mm
5
x4
6
x4
M8×17x1.2mm
10
x4
M8×18x2mm
本产品最大承受重量150公斤。请勿将150公斤以上的物体放在椅子上。
本產品最大承受重量150公斤。請勿將150公斤以上的物體放在椅子上。
配件 , 配件
组装说明 , 組裝說明
制造商联系方式 , 製造商聯繫方式
Compucase Enterprise Co.,Ltd.
All rights reserved.
COUGAR USA Technical Service
Tel: (833) 256-3778
Mail:rma@compucaseusa.com
www.cougargaming.com
O f f i ci al w eb si te
2
x2
7
x2
C
D
M5×12mm
3
4
8
x4
4
x2
M6×25mm
x2
1
2
x2
3
x4x4
5 6
7
98
x2
x1x4
4
5 mm
M8×25mm
x4
M5×12mm
M6×25mm M8×17x1.2mm
9
5 mm
x12
M8×20mm
9
5 mm
H
I
K
J
请小心把椅子立起。
請小心把椅子立起。
Carefully tilt the chair
into an upright position.
请注意需加上 号垫片。10
請注意需加上 號墊片。10
Please make sure to add washer No. 10.
5 6 7
请小心把椅背倾倒。
請小心把椅背傾倒。
Gently set it facing
downwards.
G
5-1
5-2
FRONT
E
F
7-1
7-2
5-3 5-3
x4
10
M8×18x2mm
10 10
