Sida 1/4
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.072424
SWRCR-59LV
Radio Replacement with Steering Wheel Control Retention
for Select Dodge, Fiat, Jeep and RAM Vehicles
1 of 4
RAD IO REPLACEMENT
SWC RE TENTION
+
R
INTERFACING SOLUTIONS
- Retains factory features in select Dodge, Fiat, Jeep and RAM vehicles while functioning with an aftermarket radio.
- Retains Steering Wheel Controls via built-in, pre-programmed interface.
- Provides accessory power (2A Max).
- Retains factory backup camera (composite and LVDS)
- Retains factory Aux input in select vehicles.
- Retains factory SWC phone button functionality in select vehicles.
- Retains factory Digital (Alpine amplifier) and analog amplifier.
- EIA color coded wiring for easy installation.
PRODUCT FEATURES:
PARTS INCLUDED:
INSTALLATION DIAGRAM:
SWRCR-59LV Module
Front view
Back view
SWRCR-59LV Harness SWC Cables
AFTERMARKET
RADIO
+12V Constant Yellow
Gr
ound Black
+12V
A
CC
Red
Reverse Trigger Red/White
VSS (Vehicle Speed Sense) Purple/White
Illuminaton (+) Orange
Amplifier Turn-on Blue/White
Right Fron
t (+) G
ray
Right Fron
t (-) G
ray/Black
Left Fron
t (+) Whi
te
Left Front (-) White/Black
Right R
ear (+) Viol
et
Right Rear (-) Violet/Black
Left R
ear (+) G
reen
Left Rear (-) Green/Black
To Retain Factory Aux Input Red/White RCA
To Retain OEM composite Camera* Yellow RCA
12-Pin
Connector
4-Pin
Connector
Option A:
Option B:
Cap or insulate if
not being used
BLUE / YELLOW
Insulate with tape
if not being used
3.5MM SWC CABLES (Option A or B)
Use the proper 3.5MM to 4-Pin cable for your radio.
Plug in the selected 3.5MM SWC cable to the 4-pin port
on the module. See “DIP SWITCH SETTINGS” section.
To the aftermarket
radio 3.5mm SWC
port or SWC wires
Video Cable (Male to Male)
1 2 3
ON
4
*NOTE: To Retain OEM non digital Backup Camera connect
the
video RCA directly to the aermarket radio
TO FACTORY
HARNESS
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.072424
2 of 4
RAD IO REPLACEMENT
SWC RE TENTION
+
R
INTERFACING SOLUTIONS
SWRCR-59LV
Radio Replacement with Steering Wheel Control Retention
for Select Dodge, Fiat, Jeep and RAM Vehicles
DIGITAL CAMERA RETENTION INSTRUCTIONS:
DIP SWITCH SETTINGS:
RADIO BRAND: DIP#: 1 2 3
Atoto, Dual, Fahrenheit, Jensen, Nakamichi,
Pioneer, Power Acoustik, Soundstream
Alpine
Clarion
Kenwood
JVC
Boss, Old Sony
New Sony (with CarPlay)
OFF ON ON
OFF ON ON
OFF ON ON
OFF OFF OFF
ON ON OFF
ON ON ON
ON OFF ON
ON OFF OFF
OFF ON OFF
SWC MODULE
DIP SWITCH
1 2 3 4 5 6
ON
4
*
5
*
6
*
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
Aftermarket Video RCA Factory Connector
RCA OUT
OEM Camera
(GMSL)
FAK IN
AFTERMARKET
RADIO
SWRCR-59LV Module front
(Male to Male)
OPTION A is used for ALPINE, CLARION, (JVC and KENWOOD units will use the Blue/Yellow wire).
OPTION B is used for ATOTO, BOSS, BLAUPUNKT, DUAL, FARENHEIT, JENSEN, POWER ACOUSTIK, PIONEER, SONY,
NOTE: Cap or insulate the 3.5mm plug or Blue/Yellow wire if not being used.
NOTE:
check the aftermarket radio’s manual to see if the SWC buttons need to be programmed.
RED to SWC Key 1
WHITE to SWC Key 2
SHIELD to SWC Ground
as follows:
Note that there are some radios that only have SWC1 and SWC2, in this case “shield” does not need to be connected.
Camera Version*
Camera Type 3 (ProMaster)
Small Resolution (Old Vehicles)
Large Resolution (New Vehicles)
DIP 4
DIP 5 DIP 6
OFF OFF OFF
OFF OFF
OFF
OFF
ON
ON
Setting the DIP switches for camera type
Aer each change of the DIP switch sengs you have to execute a power rest of the interface box!
SWC Troubleshoot option
Located internally
Need to take plastic
Casing o module
If Steering Wheel Controls malfunction
please switch internal dip switch from
3v3 to 5v as shown in picture above.
