Sida 1/3
2016 Kia Sorrento
- with 8” Navigaon screen.
Cable colour
Pin-No.
Assignment
● Yellow
Pin 4
CAN-HIGH connecon to the head-unit–
● Blue
Pin 3
CAN-LOW connecon to the head-unit –
●● Yellow/Black
Pin 8
CAN-HIGH connecon to the vehicle –
●● Blue/Black
Pin 7
CAN-LOW connecon to the vehicle –
● Red
Pin 1
+12V Constant
● Black
Pin 5
Ground
● Green
Pin 6
Acvaon of the Video- -Moon funcon in
(+12V = VIM Enabled )
● White
Pin 2
Trigger output (+12V DC 500mA)
VIMHK- Interface Module 97
HK- Harness 97
rev.0612 16
1 /2
Pin assignment male 8-pin connector of VIMHK- 97
Connector A Connector B
Please note that the given informaon must be veried by the installer. Crux Interfacing assumes
no liability for changes in wire color or pin assignments made by the vehicle manufacturer.
For video in moon, cut and insulate the analog speed signal wire (pin 17, connector B)
(navigaon will sll work over GPS recepon An oponal toggle switch can be installed in ).
between the cut speed signal wire in case the GPS recepon is bad or not available.
Connector
Assignment
Connector B, Pin 11/12
+12V Constant (Red)
Connector B, Pin 23/24
Ground (Black)
Connector B, Pin 1
CAN-HIGH (Yellow)
Connector B, Pin 13
CAN-LOW (Blue)
Connector B, Pin 16
Speedsignal (Gray)
rev.0 61216
2 3 /
DIP Switch Seng
Vehicle/ Navigaon
Dip 1
Dip 2
Dip 3
Dip 4
Dip 5
Dip 6
All vehicles
ON
OFF
OFF
OFF
OFF
OFF
DIP Switch Funcons:
Dip 1 ON = Video In Moon enabled –
Dip 2 ON = If factory rear-view camera is present –
Dip 3 no funcon (set to OFF) –
Dip 4 no funcon (set to OFF) –
Dip 5 CAN-bus terminaon resistor on the vehicle side –
Dip 6 CAN-bus terminaon resistor on the head-unit side –
Acvaon of the Video-In-Moon funcon
The Video- -Moon can be acvated and deacvated by DIP 1 or by the loose green wire on the In
harness when connected to a +12V ACC source.
Video- -Moon permanent In
With DIP1 set to ON, the video- -moon funcon is acvated permanently without disturbing the in
navigaon performance.
Video- -moon selecve in
With DIP1 set to OFF, the green wire is used to acvate and deacvate the video- -moon funcon. in
Connect a toggle switch between the green wire and +12V ACC.
● +12V = Video- -moon is acvated in
● 0V = Video- -moon is not acvatedin
rev.0 61216
3 3 /
