2. Install Hand Shower

In2ition

Installation Instructions

Parts Included

Shower Head

Hand Shower

3. Insert Hand Shower into Shower Head

a. Slide Hand Shower

into the top of the

Shower Head.

b. Gently push the

Hand Shower

down into the

Shower Head.

• If the Shower

Head moves when

inserting or

removing the

Hand Shower,

hand tighten the

connection

between the

Shower Head and

the Ball Connector.

Place the hose washers into the hose nuts on each end

of the hose.

Attach the end of the hose with a hex nut to the

shower head. Connect the other end of the Metal Hose

to the Hand Shower. All connections should be able to

be made by hand tightening only.

To change spray modes, turn the lever (located on the

front of the Hand Shower) left or right to the desired

setting.

Metal Hose

1. Install the Shower Head

4. Removing the Hand Shower from the Shower Head

Push the lower part

of the Hand Shower

upwards, away from

the Shower Head.

Pull the Hand

Shower away from

the slot in the

Shower Head.

Hose Washer

(2)

Turn off water supply before installing the Shower Head.

Remove existing Shower Head from Shower Arm.

Apply plumber tape (not included) to Shower Arm, if necessary,

to stop or prevent leaks.

Hand tighten the Ball Connector of the Shower Head to the

Shower Arm.

2a. Changing Modes From Shower Head, to Hand Shower, or to Both

Turn knob on side of Shower Head to change between:

• Shower Head only

• Shower Head and Hand Shower

• Hand Shower only

6467 Rev. C07/03/2020

Control

Knob

Hex Nut

Ball Connector

WARNING:

Notice: Removal of or tampering with the flow restrictor may result in showerhead failure and will void the warranty.

Backflow Protection

If your product is not equipped with backflow prevention, in order to make your product backflow compliant, a vacuum breaker will need to be added.

Plumbing Codes require that shower heads and hand showers provide a small but continuous ﬂow of water (trickle) when in “PAUSE” mode. Because of this continuous ﬂow, in certain circumstances

pressure variations in the water line and/or changes in the position of shower temperature control handle while in “PAUSE” mode could result in dramatic changes to the temperature of the water when the shower

head or hand shower is returned to the “ON” position.

ALWAYS point the shower head away from yourself when returning to the “ON” position and feel the water with your hand before resuming your shower to ensure the water ﬂow is not too hot or too cold. DO NOT

allow children or others who might not understand this warning to use the “PAUSE” function.
