Sida 1/8
ENG-1
CCT-1301
USER MANUAL
www.facebook.com/denverelectronics
ENG-
2
For the power capacity in the battery, refer to the following icons:
Full
Middle
Low
1 .Connect device to car adaptor through Mini-USB port, device will power on automatically &
enter standby mode and start charging with red indicator light ON. Once device has been fully
charged, red indicator light goes out.
2. Connect device to PC via USB cable, device will power on automatically and start charging.
Once device has been fully charged, red indicator light goes out.
Installation and Removal of micro SD card
1. In the direction as indicated, insert the micro SD card into the slot until it is held firmly.
2. To take the micro SD card out, slightly press the micro SD card to eject it out.
[Note]:
1. Observe the direction to insert the micro SD card; if the direction is wrong, the device and/or
the micro SD card may be damaged.
2. When the micro SD card is inserted into the device, the machine will set the micro SD card as
preset storage.
3. If the micro SD card is incompatible with the device, please insert the card again or replace it
for retry.
1.Shutter
2.Speaker
3.ON/OFF
4.USB port
5.Micro SD card slot
6.Lens
7.Charging indicator
light
8.Busy indicator light
9.Cover
10.Screen
11.Mode
12.Menu
13.AV port
14.Down (Zoom out)
15.Up (Zoom in)
16.Tripod slot
ENG-3
4. PLEASE USE 8GB-32GB/CLASS 10 (C10) MICRO SD CARDS ONLY.
5. Please insert the micro SD card ONLY when device is OFF.
Operation Instructions
Turn ON/OFF Device
1. Press the ON/OFF key for 1 second to switch ON and hold for 1 seconds to switch OFF device
manually.
2. Connect the device with car charger in the car. When car engine starts up, device will be
switched ON automatically. When car engine shuts off or car charger been disconnected,
device switches OFF with 10 seconds delay.
How to Enter System Setup
In Video / Photo / Vehicle mode, continuous press the Menu key to select the System Setup, press
the UP/Down - shutter key to setting:
- Sound Effect:
Shutter: [on]/[off]
Start-up: [on]/[off]
Beep: [on]/[off]
- Frequency:
[50HZ]/ [60HZ]
- Auto Power Off:[OFF]/[1min]/[2min]/[3min]
- Language: You may set the desired OSD language menu.
[German]/[Danish]/[Spanish]/[French]/[Italian]/[Dutch]/[Polish]/[Portuguese]/[Swedish]/
[Finnish]/[English]
- TV Mode: [NTSC] / [PAL]
- Format: Format the memory card. [YES ]/[NO]
- Default Setting:[YES ]/[NO]
Take Video and Set Video Menu
1. Take video
When its powered of enter the Vehicle mode as default; press the Mode key to enter the video
mode with icon displaying at the upper-left corner of screen. Press the ‘Shutter’ key to start
video recording after proper Micro SD card been inserted. During recording, the red icon
flashes. To stop, press and hold power 2 second.
2. Set Video Menu
Press Menu to switch this options.
- Video Resolution :[1280*720 HD]/[640*480 VGA]
- Loop recording time: [3 Minutes]/[5 Minutes]/[10 Minutes]/[off]. To record, store and recycle the
video file by 3/5/10 minutes per section.
- Date: [on]/[off]/[Set Date].
- Setup: Refer to setting the System Setup.
Produktspecifikationer
| Varumärke: | Denver |
| Kategori: | Dashcam |
| Modell: | CCT-1301 |
