Sida 1/31

GreenPhy Module
SDK How-To
devolo AG . Charlottenburger Allee 60 . 52068 Aachen . Tel.: +49 (0) 241 182 79 0 . Fax: +49 (0) 241 182 79 999 . www.devolo.de . info@devolo.de
DESCRIPTION
The dLAN® Green PHY Module is an integrated device for transmitting and receiving data
over the power line. It holds all functions necessary for the easy creation of Green PHY
network devices.
The QCA7000 Green PHY processor is supported by an LPC1758 host processor for
additional interfaces and functionality.
Delivery status:
The module supports Ethernet to PLC bridging functionality.
It will automatically join a standard powerline network with default network password
“HomePlugAV”. The network password may be changed by user interaction.
A TFTP client boot loader is executed at start up and loads firmware from a TFTP server.
Customers are enabled to add or adapt functionality to their special needs by modifying the
host processor firmware using this SDK (Software Development Kit).
For further hardware related issues, please see Green PHY Module data sheet.
Version
V1.0.1: Initial release
V1.0.2: ‘Changing the Build Configuration’ added
V1.0.3: Minor changes
V2.0.0: Added Support for Clickboard Sensors (mikroBUS standard)
V2.1.0: MQTT Protocol (for relayr and other cloud platforms) implemented, DNS and DHCP
Client added

GreenPhy Module
SDK How-To
devolo AG . Charlottenburger Allee 60 . 52068 Aachen . Tel.: +49 (0) 241 182 79 0 . Fax: +49 (0) 241 182 79 999 . www.devolo.de . info@devolo.de
Contents
1 Introduction .................................................................................................................................. 4
1.1 Deliverables......................................................................................................................... 4
2 Installation .................................................................................................................................... 5
2.1 Download, install and activate LPCXpresso ....................................................................... 5
2.2 Import of the SDK Sources ................................................................................................. 5
3 Components ................................................................................................................................. 8
3.1 LPCXpresso ........................................................................................................................ 8
3.2 Included Projects ................................................................................................................. 8
3.3 GreenPhy Module SDK supporting Packages .................................................................... 8
3.3.1 CMSIS v2.00 ................................................................................................................... 8
3.3.2 FreeRTOS V7.1.0............................................................................................................ 8
3.3.3 Hardware Support ........................................................................................................... 8
3.3.4 Application Support ......................................................................................................... 9
3.4 GreenPhy Module Firmware ............................................................................................... 9
3.4.1 Firmware Standalone ...................................................................................................... 9
3.4.2 Firmware Image for TFTP update ................................................................................... 9
3.5 Configuration ....................................................................................................................... 9
4 Usage ......................................................................................................................................... 11
4.1 Configuration of the firmware build ................................................................................... 11
4.2 Building the firmware ......................................................................................................... 11
4.2.1 Changing the Build Configuration ................................................................................. 12
4.3 Programming the firmware to the Module ......................................................................... 13
4.3.1 JTAG ............................................................................................................................. 13
4.3.2 UART0 ........................................................................................................................... 13
4.3.3 TFTP ............................................................................................................................. 14
5 Examples ................................................................................................................................... 15
5.1 ETH GreenPhy Bridge ...................................................................................................... 15
5.2 Webserver ......................................................................................................................... 15
5.3 Bootloader with TFTP client for firmware update .............................................................. 15
6 Evaluation Board ........................................................................................................................ 16
6.1 mikroBUS .......................................................................................................................... 21
6.2 Webserver ......................................................................................................................... 21
6.3 Clickboards ........................................................................................................................ 16
6.3.1 DALI Click ...................................................................................................................... 14
6.4 Add new Clickboards ........................................................................................................ 17
Produktspecifikationer
Varumärke: | Devolo |
Kategori: | nätverkskort/adapter |
Modell: | 9724 |
Maximal dataöverföringshastighet: | - Mbit/s |
Produktens färg: | Multifärg |
Datahastighet för Ethernet-LAN: | 100 Mbit/s |
Antal LAN (RJ-45) anslutningar: | 1 |
Temperatur vid drift: | 0 - 70 ° C |
Utgångsspänning: | 5 V |
Anslutningsteknologi: | Kabel |
Nätverksansluten (Ethernet): | Ja |
Intern: | Ja |
Ingående ström: | 0.32 A |
