Sida 1/8
Fault nding 6
Maintenance 7
Compliance with regulations 8
Contents
Presentation 1
Installation 1
Using and safety 3
Cleaning, hygiene and storage 5
1. DESCRIPTION1
• This universal vegetable preparation machine may be used
for cutting, slicing, shredding, grating, making chips and dicing.
Its range of assorted cutting equipment provides high rates of
output and its two interchangeable feed hoppers which adapt to
the user’s requirements make the TR300 the professional vege-
table preparation machine for catering and the food industry alike.
A Stainless steel casing
B Storage space
C Body
D Hopper support cover
E Automatic hopper
F Electric controls
G Locking lever
1. TECHNICAL DESCRIPTION2
This vegetable preparation machine consists essentially of the
following:
• A stainless steel casing on castors containing:
- The motor and the electrical controls,
- A storage space for the cutting equipment, located in the lower
part.
•
A cast aluminium body attached onto the casing, containing:
- The gear reduction mechanism,
- The drive for the cutting and ejection equipment.
• A cast aluminium hopper support cover which is hinged at the
back and locked at the front.
• Two swivelling, interchangeable feed hoppers suited to the
dierent types of work:
- The automatic hopper with a rotating feed-screw controlled by
a geared reducer.
- The special long vegetable hopper which has 9 tubes of die-
rent lengths and diameters.
• Various items of cutting equipment including:
- Slicing, shredding and grating plates of 300 mm diameter with
a standard ejector,
- Dicing grids,
- Chip accessories with rotating cutting discs and a special chip
ejector.
1 TR300 GB 06 2016
Presentation
GB
03/2024
This document is to be used in conjunction with the original manufacturer’s manual.
The symbols correspond with the numbered drawings of the original manual.
1.1
Introduction
The User Manual contains useful information for the user on how
to work correctly and in complete safety, and is designed to make
it easier to use the machine (called «machine» or «appliance»
below).
What follows is in no case intended to be a long list of warnings and
constraints, but rather a series of instructions meant to improve the
service provided by the machine in every respect, and particularly
to avoid a series of injuries or damage to equipment that might
result from inappropriate procedures for use and management.
It is essential that all the people responsible for transporting,
installing, commissioning, using, maintaining, repairing or dis-
mantling the machine should consult this manual and read it
carefully before proceeding with the various operations, in order
to avoid any incorrect or inappropriate handling that might be
result in damage to the machine or put people’s safety at risk.
It is just as important that the Manual should always be available
to the operator and it should be kept carefully where the machine
is used ready for easy and immediate consultation in case of any
doubt, or in any case, whenever the need arises.
If after reading the Manual, there are still any doubts concerning
how to use the machine, please do not hesitate to contact the
Manufacturer or approved After Sales Service provider, who is
constantly available to ensure quick and careful service for im-
proved machine operation and optimum eciency.
Note that the safety, hygiene and environmental protection stan-
dards currently applicable in the country where the machine is
installed must always be applied during all phases of machine
operation. Consequently it is the user’s responsibility to ensure
that the machine is operated and used solely under the optimum
safety conditions laid down for people, animals and property.
Installation
ATTENTION!!
Machine storage: -25°C to +50°C
Ambient temperature during operation: +4°C to +40°C
This machine is for professional use and must be used by sta trained to use, clean and maintain it, in terms or reliability and safety.
Use the machine in adequately lit premises (See applicable technical standard for the country of use. In Europe, refer to standard
EN 12464-1)
When handling the machine, always check that the parts taken hold of are not mobile elements: risk of dropping and injury to the
lower limbs.
The machine is not designed for use in explosive atmospheres.
The machine is delivered without wheels or skids for mounting refer to the installation sheet.
The reference language for these instructions is French.
