Sida 1/5
Installation Instructions: C100 and C200 1DT and C100 2DT Dummy Trim Assemblies
DORMA-C100/C200 series
10-2021 1T93465_A www.dormakaba.us
Installation Instructions
C DT and DT dummy trim assemblies
Technical specifications
Installation instructions
. Tools recommended
Table
Fig.
Fig.
Fig.
. Overview
Liner
Rose
Lever
Sleeve
Liner
Rose
Lever
Sleeve
.. Disengage the lever by
pushing the pointed end
of the spanner wrench
into the hole on the lever.
.. Slide the lever off.
.. Unscrew the rose from
the sleeve.
.. Using the spanner wrench,
pry the rose from the liner.
.. Draw a height line across the face of the door. The
suggested height is -/" ( mm) from the
finished floor.
.. Place the template on the door.
.. Mark and drill the two holes.
.. Fasten the sleeve onto the door with the screws provided.
.. Thread on the liner until it seats against the door.
.. Install the outside trim assembly with studs on the outside
of the door.
.. Align the inside sleeve and secure using the screws provided.
.. Thread on the inside liner until it seats against the door.
..
Press the rose over the liner until it fits flush against the door.
.. Press on the lever.
..
Press on the rose over the liner assembly.
.. Press on the inside lever.
. Disassemble dummy trim.
. Mark and drill holes.
. Install dummy trim.
NOTE: For C double dummy trim, disassemble the
inside trim assembly only. There is no need to disassemble
the outside trim.
NOTE: For pairs of doors, install the dummy trim at the
same height and backset distance from the edge of the
door to the center of the lock trim on both the active and
inactive doors.
NOTE: Slide the liner onto the sleeve in the opposite way from
the normal installation.
NOTE: Slide the liner onto the sleeve in the opposite way from
the normal installation.
NOTE: For single dummy trim, drill two pilot holes halfway
through the door with a /" (1.5 mm) drill bit. For double
dummy trim, drill two holes completely through the door
with a /" (7 mm) drill bit.
Fig.
Fig.
Fig.
Outsid assemblye
with studs
L
ever
Machine scre
ws
Insid sleevee
Insid linere
Outsid assemblye
with studs
L
ever
Machine scre
ws
Insid sleevee
Insid linere
For C double dummy trim
For C single dummy trim
C double dummy trimC single dummy trim
Spa
n rne
wr chen
Rose
Spa nen r
wrench
Hole
(n )ot shown
Lever
# & # Phillips screwdriver
Spanner wrench
Tape measure
Lever keeper tool
Pencil
Drill bit: /" (1.5 mm) drill bi
t
Dril
l
