E-PLEX

11/ ” MORTISE INSTALLATION INSTRUCTIONS4

TABLE OF CONTENTS

Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Exploded Install Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

A. Mortise Handing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

B. Door Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

C. Installing the Strike . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

D. Installing Outside Unit Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

E. Installing Inside Unit Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

F. Installing the Inside Lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

G. Changing Key-In-Lever Cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

H. Installing / Removing Outside Lever (Key-In-Lever) KIL . . . . . . . . . . . . . . . . . . . . . . . . .18

I. Installing / Removing Outside Lever (Interchangeable/ . . . . . . . . . . . . . . . . . . . . . . . . .18

removable core models)

J. Installing the Battery Pack and Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

K. Testing the Operation of the Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

L. Programming and Software Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

M. Installing Rubber Bumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Warning:The Master Code of this lock has been factory preset:

1,2,3,4,5,6,7,8. To activate lock functions, the master combination

must be changed at time of installation.

Warnings and Cautions

Important: Carefully inspect windows, door frame, door, lights, etc.

to ensure that the recommended procedures will not cause damage.

Kaba Access Control’s warranty does not cover damages caused by

installation.

Caution: Wear safety glasses when preparing door.

Introduction

The purpose of this manual is to instruct the installer on the proper installation

procedure for the E-Plex 5x66 and 5x67 1 1⁄4" American Steel Mortise (ASM)

Mortise locks. These instructions pertain to models with and without deadbolts.

For models without deadbolts, please disregard any references to a thumbturn

in the instructions.

TOOLS REQUIRED

• Safety glasses

• 1⁄2" (13 mm) chisel

• 1⁄8" (3 mm) drill bit

• 1⁄4" (7 mm) drill bit

• 1⁄2" (13 mm) drill bit

• 21⁄8" (54 mm) hole saw

• Drill

• Awl or center punch

• Hammer

• Small flat screwdriver

• Phillips screwdriver (#2)

• Fine steel file

• Mortising machine

• Router

• Mortise faceplate router

template

• Adjustable square

• Tape measure

• Pencil

• Tape

• Cleaning supplies

(drop cloth, vacuum)

OPERATIONAL NOTE:

The E-Plex Mortise lock is almost identical to the E-Plex 5000

Cylindrical lock with the following exceptions:

1. Operation of the Lever When the lock’s handing is properly

set, only a downward rotation of lever will actuate latch.

2. Key Override Use The key override differs in that rotating

the key does not actuate the latch. To use the key override

the key must be inserted into the cylinder and rotated count-

er clockwise until it stops (approximately 90 degrees) then

while holding the key in this position with one hand use the

other hand to rotate the lever downward to retract the latch.

Once the lever has rotated a few degrees the key may be

released.
