Subject to change without notice
HSB-E02 sensor barriers
Moderate
Standard unitsHSB-E02
Note:Description of single unit
Interlock height40-3⁄16" (1020)
Interlock length 69-5⁄16" (1760)
Passage width 25-9⁄16" (650)
Total width 41-5⁄16" (1050)
Housing, base columns,
guiding elements
AISI 304 stainless steel with satin finish.
ADA compliance36" (915) width available.
Barrier elements Two door leaves made of transparent polycarbonate;
upper edge 35-7⁄16" (900).
Swinging area monitored by separation sensors.
SecurityPassage area monitored by basic sensor system with a compact
installation length (basic level of single passage monitoring in
both directions).
FinishStainless steel semi-gloss smooth finish.
SafetyLow energy drive with energy content less than 1.18 lb/ft.
FunctionType 2-power assisted motion; two servo-positioning drives/
electrically controlled in both directions.
DrivesIntegrated in the swing tube.
Operating modesOptical.
Normally closed.
Normally opened. (Barriers close on tailgate event.)
Electrical equipmentControl system and power supply integrated in the unit.
Power supply110 – 230 VAC, 50/60 Hz. 368 VA
Standby power
consumption
17 VA
Standard adjustment in
case of power failure
Door leaves move freely.
InstallationDowelled on finished floor level, FFL.
Not suitable for outdoor installation.
Protection classesHousing IP43, components conducting supply voltage IP43.
41-5/16"
(1050)
7-7/8"
(200)
7-7/8"
(200)
69 -9/16"
()1760
35-7/16"
(900)
40-3/16"
(1020)
56 -3/4"
(1440)
25-9/16"
(650)
HSB-E02
Moderate units offer
tailgating monitoring.
Entrance systems
