Sida 1/2
Subject to change without notice
79-1/8"
(2010)
79-1/8"
(2010)
35-7/16"
(900)
37-3/16"
(945)
HSB-E08
42-1/8"
(1070)
25-9/16"
(650)
HSB-E08 sensor barriers
Premium
Standard units HSB-E08
Note: Description of single unit
Interlock height 37-3/16" (945)
Interlock length 79-1/8" (2010)
Passage width 2-9/16" (650)
Total width 42-1/8" (1070)
ADA compliance 36" (915) width available.
Housing, base columns,
guiding elements
AISI 304 Ø2-3/8"(Ø60) stainless steel tube with 3/8" (10) toughened
safety glass panel and AISI 304 stainless steel handrail as well as
horizontaland vertical sensors mounted on the guiding elements.
Security Passage area monitored by enhanced sensor system with an optimized
installation length and arrangement (increased level of single passage
monitoring in both irections). Integrated sneak-by guard, detection of
children and luggage or rolling cases.
Barrier elements Two door leaves made of transparent polycarbonate, upper edge
35 7⁄16" (900).
Swinging area monitored by separation sensors.
Finish Stainless steel semi-gloss smooth finish.
Safety Low energy drive with energy content less than 1.18 lb/ft.
Function Type 2–power assisted motion; two servo-positioning drives/electrically
controlled in both directions.
Drives Integrated in the swing tube.
Operating modes Optical.
Normally closed.
Normally opened. (Barriers close on tailgate event.)
Electrical equipment Control system and power supply integrated in the unit.
Power supply 110 – 230 VAC, 50/60 Hz. 368 VA
Standby power
consumption
17 VA
Standard adjustment in
case of power failure
Door leaves move freely.
Installation Dowelled on finished floor level, FFL.
Not suitable for outdoor installation.
Protection classes Housing IP32, components conducting supply voltage IP42.
Premium units offer tailgating
monitoring. The enhanced
sensor system includes
luggage and child detection.
Entrance systems
