Keyscan CA8500
8-Reader Access Control Unit
With an emphasis on innovation and sustainability, you can
trust the Keyscan CA8500 access control unit for smart
access control technology and system design flexibility.
Keyscan CA series of door controllers are compatible and
merge security with convenience. The CA series can satisfy
any new installation requirement or augment existing
Keyscan systems while, in many cases, utilizing existing
infrastructure including credentials.
CA8500 includes:
• CA8500B ACU board
• 2-OCB8 relay boards
• 1-DPS-15 power supply
• 1-black metal enclosure with lock and tamper switch
Keyscan CA8500 features:
• Network TCP/IP ready
• Easily configurable reader settings supporting many
Wiegand protocols
• Auto-transfer protocol uploads transaction buffer
if interruption occurs
• Dual processors
• Lock down and global communication among multiple
ACUs, server and sites (requires CIMs and CIM Link)
• Multiple inputs and outputs for expansion capability
Strike or
Electromagnetic
lock
Door contact
RTE
Keyscan or
compatible
readers
6 Conductor shielded 18 or
22GA. Max Distance 500 ft
IOCB1616 16 input/16
output (optional)
8 aux output relays
2x 16.5VAC, 37 or
40VA transformers
(not supplied)
12VDC / 7AH
back up battery
(not supplied)
16 Aux Alarm Inputs
(N/C, single or dual
resistor supervision)
If using multiple panels: A
CIM is required per controller
when there is more than one
controller on the
communication bus.
2 twisted pair (Cat5)
8 pre-alert output relays
8 accessibility output relays
8 global outputs
LAN
WAN
Cat5
Remote sites (Reverse
Network Option)
CIM
Produktspecifikationer
| Varumärke: | Dormakaba |
| Kategori: | Inte kategoriserad |
| Modell: | Keyscan CA8500 |
