HTS-E03

Waist height turnstiles

Standard unitsHTS-E03

Construction

MaterialAISI 304 stainless steel / toughened safety glass, 3/8" (10 mm).

Side barrier elementsMade of AISI 304 stainless steel tubing Ø1-7/8" (Ø48 mm),

mitered.

Rotating unitsWith tubular column Ø5-1/2" (Ø140 mm) made of AISI 304 stainless

steel.

With three glass elements and stainless steel bar handles. Glass

elements are one of:

Option 1: Three tall glass elements

Option 2: Three bevelled glass elements

Option 3: Three half-height glass elements

Locking system, drive & toothed clutch installed in tubular column.

FinishStainless steel satin finish.

FunctionPower assist; servo-positioning drive/electrically controlled in 2

directions.

Passage side can be selected: inwards right or inwards left.

Electrical equipmentControl unit in external switch cabinet:

H 11-1/8" × W 6-5/8" × D 4-1/2" (H 283 mm × W 168 mm × D 115 mm).

Power supply110 – 230 VAC, 50/60 Hz, 253 VA.

In case of power failure both directions free.

Standby power consumption15 VA.

InstallationFinished floor.

Not suitable for outdoor installation.

Protection classesHousing IP43, components conducting supply voltage IP54.

Option 1

Option 2

Option 3

Subject to change without notice
