INSTALLATION
RCI 0163 / RCI 0163LM
SURFACE MOUNTED RIM STRIKE
© 2018 dormakaba Canada Inc
www.dormakaba.us • Phone: 1.800.265.6630 • Fax: 1.800.482.9795 • E-mail: sales_RCI@dormakaba.com
Fail Secure = Fail Locked = FL AC = Alternating Current DC = Direct Current
Intermittent Duty = Energized less than 1 minute with 1:5 duty ratio Continuous Duty = Energized 1 minute or more
IS0163 PCN18041
R09-18GR-3
Important: The RCI 0163 Electric Strikes should never be used as a door stop.Please install stops on frame in
appropriate locations. Ensure the exit device functions as intended for life safety concerns by verifying electric strike and
exit device compatibility. Maximum latch projection is essential to obtain full holding force.
Since the RCI 0163 strike is fail secure the local Authority Having Jurisdiction shall be consulted with regard to the use
of selected panic hardware to ensure emergency exit from the secured area.
Installations of this RIM strike qualify as “Indoor Use Only” when not continuously exposed to an outdoor environment.
Catalog Specifications
MODE VOLTAGE CURRENT DUTY
PEAK AMPS
OHMS
Fail Secure 12V AC Intermittent 0.15 37
Fail Secure 12V DC Continuous 0.27 37
Fail Secure 24V AC Intermittent 0.33 37
Fail Secure 24V DC Continuous 0.14 148
Fail Secure 11-16V AC Intermittent 0.13-0.19 37
Electrical Latch Monitor
Specification:
• 12VDC, 1A, resistive load
Note: Contacts identified on the
harness sleeve are indicated with the
keeper in a closed and locked condition,
with no latch present
Dimensional Details
UL 294 Performance Ratings:
Access Control Line Security : Level I
Destructive Attack : Level I
Endurance : Level IV
Standby Power : Level I
