Sida 1/2
Subject to change without notice
• How BLUEZONE works. When the
approach area detects a person
or object, the sensor activates the
door and turns on the BLUEZONE,
which detects through the
threshold. As long as someone is
in the detection area, the sensor
keeps the door in the open position.
Once the area is cleared, the
BLUEZONE ignores the door panels
and allows the door to close safely.
• Adapted to cold environments.
The dormakaba combination
activation and presence sensor
operates in temperatures ranging
from a low of -31°F to a high of
+131°F (-35°C to +55°C).
• Monitoring capability. With its
built-in monitoring capability, this
combination activation and
presence sensor monitors all its
critical functions and notifies
compatible controls when an error
occurs. Self-monitoring ensures a
higher level of performance over
the life of the sensor.
Combination activation &
presence sensor
Automatic sliding & swinging doors
Entrance systems
Description
dormakaba’s combination activation and presence sensor offers fexibility for
more safety and more reliability. With its presence detection capability, the
sensor can use detection area as presence detection area—making a variety of
applications possible. This unit complies with new ANSI standard.
Features & benefits
EO 8.18
dormakaba Canada
1680 Courtney Park Dr. Unit 13
Mississauga, ON L5T 1R4
800.387.4938
www.dormakaba.ca
dormakaba USA Inc.
Dorma Drive, Drawer AC
Reamstown, PA 17567
844-SPECNOW
www.dormakaba.us
Technical specifications
Model OA-FLEX T
Cover color Black
Mounting height 6' 7" (2 m) to 8' 2" (2.5 m)
Detection method Active infrared reflection1
Area angle adjustment Depth: -8° to +8°
Width: ±7°
2 clicks with 3.5° every click – Left/Right
Power supply 112 to 24 VAC ±10% (50 / 60Hz)
12 to 30 VDC ±10%
Power consumption <2.0 W (<5 VA at AC)
Operating humidity <80%
Test input Opto coupler
Voltage / 5 to 30 VDC
Current / 6 mA max. (30 VDC)
Activation output Form A relay
50 V 0.3 A max. (Resistance load)
Safety output Form A relay
50 V 0.3 A max. (Resistance load)
Operating temperature -31°F to +131°F (-35°C to +55°C)
Noise level <70 dBA
Output hold time Approx. 0.5 sec.
Response time <0.3 sec.
IP rate IP54
Weight 7.8 oz (220 g)
Accessories 1 Operation manual
2 Mounting screws
1 Mounting template
1 Area adjustment tool
1 Cable 9'10” (3 m)
8 × 0.22 mm2 AWG242
1 When using this sensor, it has to be connected to a door system
that has the SELV circuit.
2
Overcurrent protection with less than 2A.
Combination activation & presence sensor for automatic swinging doors
DX3335-028 dimensional drawing
9-5/8" (245)
4-15/16" (125)
1-11/16"
(43)
1-7/16"
(36)
5/16" (7.5)
2-11/16" (68)
1-7/16"
(37)
