PIL-S01

Cylindrical personal interlock

Subject to change without notice

Standard unitsPIL-S01

Construction

Outside diameter40-3/16" (1020 mm) 44-1/16" (1120 mm)

48" (1220 mm) 52" (1320 mm)

55-5/16" (1420 mm) 59-13/16" (1520 mm) 63-3/4" (1620 mm)

Passage width20-1/2" (520 mm) 22-13/16" (580 mm)

25-9/16" (650 mm) 27-15/16" (710 mm)

30-11/16" (780 mm) 33-1/16" (840 mm) 35-13/16" (910 mm)

Total height90-9/16" (2300 mm)

Passage height82-11/16" (2100 mm)

Upper part of body7-7/8" (200 mm)

Body

Side panelsWith glass panel, option for metal-clad.

InteriorBlack rubber floor mat.

Sliding doorsMetal profiles with curved glass.

FinishAnodized aluminum, powder coated, and stainless steel.

FunctionDoor leaves with locking system.

Default position inside and outside closed.

Automatic opening and closing of both door leaves consecutively.

Emergency release button inside the interlock opens the outer

door. Manual override is optional.

Threshold protection sensor, designed to prevent an open door

from closing when a person is in the detection zone.

In the event of a power failure, the inside door will operate fail

secure and the public door will operate fail safe.

PIL Vision/anti-piggybacking.

Interior biometrics.

Electrical equipmentNetwork-compatible ETS 22 CAN bus control unit integrated in

the unit.

Power supply 230 VAC, 50 Hz.

InstallationOn stainless steel floor element with guide rail for sub floor level SFL,

measure X = 2-3/4"–3-1/8" (70–79 mm).

The ambient conditions must be checked for outdoor installation.
