Sida 1/9
DVDO-Switcher- -ARC 41
4K 4x1 HDMI Switcher with ARC Support
DVDO, Inc. │ +1.408.213.6680 │ support@dvdo.com │ www.dvdo.com
User Manual
Version v1.0
Thank you for purchasing DVDO-Switcher- -ARC 41
For optimum performance and safety, please read these instructions carefully
before connecting, operating adjusting this product. Please keep this or
manual for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged
by electrical spikes, surges, electric shock, lighting strikes, etc. Use of surge
protection systems is highly recommended order protect extend the in to and
life your equipment.of
Table of Contents
1. Introduction. ........................................................................................ 1
2. Features. .............................................................................................. 1
3. Package Contents. ............................................................................. 1
4. Specifications. ..................................................................................... 2
5. Operation Controls and Functions. .................................................... 3
5.1. Front Panel. ................................................................................. 3
5.2. Rear Panel. .................................................................................. 4
6. IR ............................................................................................ Remote. 4
7. Application Example. ......................................................................... 5
1/6
1. Introduction
This 18Gbps HDMI 4x1 Switcher can switch any four HDMI sources to one
HDMI display. It supports video resolution up to 4K2K@60Hz RGB/YCbCr
4:4:4. It supports ARC/eARC function (only for the “INPUT 1(eARC)” port),
10bit HDR and CEC function. It also supports advanced EDID management
(AUTO/2.0CH/5.1CH/7.1CH selectable). Flexible control via front panel
buttons IR remote control.and
2. Features
☆ HDMI 2.0b, 2.2 / 1.x HDCP and DVI 1.0 compliant
☆ Video resolution up to 4K2K@60Hz RGB/YCbCr 4:4:4
☆ Support 18Gbps video bandwidth
☆ Support 3D, HDR, HDR10, HDR10+, Dolby Vision pass-through
☆ Supported audio formats: LPCM, Dolby Digital/Plus/EX, Dolby True HD,
Dolby Atmos, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS- MasterHD
Audio, DSD
☆ Support auto/manual switching mode for input source
☆ Support ARC/eARC function
☆ Support advanced EDID management (AUTO/2.0CH/5.1CH/7.1CH
selectable)
☆ Flexible control via front buttons panel or IR remote control
3. Package Contents
① 1 × 18Gbps HDMI 4x1 Switcher
② 1 × 5V/1A Power Adapter (USA Standard)
③ 1 × IR Remote
④ 1 × User Manual
