MXVFullProductRange

4KHDR4:4:460HzHDBaseTMatrixSwitchers

WithZoneAudioDe-EmbedOutputs

QuickstartGuide

WyreStormrecommendsreadingthroughthisdocumentinitsentiretytobecomefamiliarwiththeproduct’sfeaturespriortostartingthe

installationprocess.

IMPORTANT!InstallationRequirements

•Visittheproductpagetodownloadthelatestrmware,documentversion,

additionaldocumentation,andcongurationtools.

•ReadthroughtheWiringandConnectionssectionforimportantwiring

guidelinesbeforecreatingorchoosingpremadecables.

•WhilethisproductsupportsCECfortheHDMIoutputs,WyreStormcannot

guaranteecompatibilitywithallformsofCECcommunication.

IMPORTANT!InstallationRequirements

•Theuseofpatchpanels,wallplates,cableextenders,kinksincables,and

electricalorenvironmentalinterferencewillhaveanadverseeffecton

signaltransmissionwhichmaylimitperformance.Stepsshouldbetaken

tominimizeorremovethesefactorscompletelyduringinstallationfor

bestresults.

•ItissuggestedtouseshieldedCat6acablingorhigherforallHDBaseT

connectionstoachievethemaximumsignaltransmissiondistanceand

reliability.Categorycablesshouldbetestedto500Mhzacrosstheentire

link.UsingCategorycablesthatdonotpassa500Mhzfrequencymay

resultinshorterdistanceandsignalloss.

•WyreStormrecommendsusingpre-terminatedHDMIcablesduetothe

complexityoftheseconnectortypes.Usingpre-terminatedcableswill

ensurethattheseconnectionsareaccurateandwillnotinterferewiththe

performanceoftheproduct.

MXVFullProductRangeQuickstartGuide|220105

INT:+44(0)1793230343|US:844.280.WYRE(9973)

[email protected]

1of2

IntheBox

1xMXVMatrixSwitcher

1xACPowerCordwithUS/UK/EU/AUpins

1xIRRemote(CR2025BatterynotIncluded)

4/6/8xIREmitters

4/6/8xIRReceivers

2xMatrixMountingBracketswithscrews

1xQuickstartGuide(thisdocument)

AdditionalIntheBox(KIT)

2xStandardHDBaseTReceivers

2xScalingHDBaseTReceivers

1xIRReceiverforMatrixIRExt.

8xReceiverMountingBracketswithscrews(2perRX)

IdentifyingProductVersions

Theseproductshavebeenreleasedundermultipleversionswhichcontain

eitherdifferentchassisdesignsand/orfeaturesets.ContentwithinthisQSG

isfortheversion2orneweroftheseproducts.Informationonother

versionscanbefoundwithinthematchingQSG.Eachproductversionis

identiedbyav#aftertheproductnumberontheproductandouter

packaging.Notethataversionoftheseproductsmaynotcontainthis

identierwhileallversionsabovev1willhavetheversionindicated.

WiringandConnections

WyreStormrecommendsthatallwiringfortheinstallationisrunandterminatedpriortomakingconnectionstotheswitcher.Readthroughthissectioninit’s

entiretybeforerunningorterminatingthewirestoensureproperoperationandtoavoiddamagingequipment.

IRTX/RXGuidelines

•UsingWyreStorminfraredemittersandreceiversisthebestwayto

ensurethatmostIRcodingformatsaretransmittedandreceivedbythe

NetworkHDsystem.Other3rdpartyemittersandreceiverscanbeused;

however,thesedevicesmustoperateinthesamemannerasthe

WyreStormdevices.

•DuetodifferencesinIRacross3rdpartycontrolsystemstheirIRports

shouldneverbeconnecteddirectlytoaNetworkHDsystemasan

incompatibilitymayexist.WyreStormoffersacablethatcompensatesfor

voltagedifferencesaswelladjustsfordifferencesinthepinsusedwithin

theport.RefertotheCAB-IR-LINKproductpageformoreinformation.

IRTXPortPinout

ConnectionforIRTX(transmit)usesa3.5mm(1/8in)monoplug.

Tip:Anode

Sleeve:Cathode (IR Signal)

IRRXPortPinout

ConnectionforIRRX(receive)usesa3.5mm(1/8in)stereojackthatoutputs

+5VDCtopowertheincludedIRreceiver.

Tip:

Ring:IR Signal

+5V DC

Sleeve:Ground (GND)

Pin 1

Pin 8

Wire colors shown follow EIA/TIA-568B standard.

Pin 1:

Pin 2:

Pin 3:

Pin 4:

Pin 5:

Pin 6:

Pin 7:

Pin 8:

White/Orange

Orange

White/Green

Blue

White/Blue

Green

White/Brown

Brown
