EXP-SW-0x01-8K

WyreStormEssentials8K602x1and4x1HDMISwitcher

QuickstartGuide

WyreStormrecommendsreadingthroughthisdocumentinitsentiretytobecomefamiliarwiththeproduct’sfeaturespriortostartingthe

installationprocess.

IMPORTANT!InstallationRequirements

IMPORTANT!WiringGuidelines

Theuseofpatchpanels,wallplates,cableextenders,kinksincables,andelectricalorenvironmentalinterferencewillhaveanadverseeffectonHDMI

transmissionlimitingperformance.Stepsshouldbetakentominimizeorremovethesefactorscompletelyduringinstallationforbestresults.WyreStorm

recommendsusinghighqualityWyreStormEssentials8KHDMIcablessuchasWyreStormEssentialstoensurethehighestcontentperformance

available.

•Visittheproductpagetodownloadthelatestrmware,documentversion,

additionaldocumentation,andcongurationtools.

•ReadthroughthesectionforimportantguidelinesWiringandConnections

beforecreatingorchoosingpremadecables.

Copyright©2022WyreStormTechnologies|wyrestorm.com

EXP-SW-0x01-8KQuickstartGuide|220118

INT:+44(0)1793230343|US:844.280.WYRE(9973)

[email protected]

IntheBox

1xEXP-SW-0201-8KorEXP-SW-0401-8K

1xDC12VPSU(US,UK,EU,AU)

1xIRReceiverCable

1xIRRemote

1x3-PinPhoenixConnector(EXP-SW-0401-8Konly)

2xMountingBrackets(withscrews)

1xQuickstartGuide(ThisDocument)

WiringandConnections

WyreStormrecommendsthatallwiringfortheinstallationisrunandterminatedpriortomakingconnectionstotheswitcher.Readthroughthissectioninits

entiretybeforerunningorterminatingthewirestoensureproperoperationandtoavoiddamagingequipment.

RS-232Wiring

TheEXP-SW-0401-8Kusesa3-pinRS-232withnohardwareflowcontrol.

MostcontrolsystemsandcomputersareDTEwherepin2isRX,thiscanvary

fromdevicetodevice.Refertothedocumentationfortheconnecteddevice

forpinfunctionallytoensurethatthecorrectconnectionscanbemade.

EDIDDipSwitchSettings

ThedipswitchonthesplitterallowsforchangingtheEDIDmanagementanddownscaleron/offfunction.

UsethetablebelowtocongurethesplittersEDIDmodebasedontheapplication’srequirement.

Whensettingadipswitchsetting,powerofftheunitbeforemakingachange.Onceset,theunitcanbepoweredbackon.

1.“-”indicatesnoadjustmentisneeded.

2.RebootthedeviceaftersettingtheDIPswitch

tomakethesettingstakeeffect.

3.3.FixedEDIDsonlyincludeuncompressed

FRLvideodata.TotransmitDSCcompressed

FRLvideo,pleaseuseCOPYEDIDsettings.

4.FixedEDIDsallsupportaudioformatsupto

PCM2CHandcompressedaudioupto7.1CH.

FixedEDIDsdonotsupportHBR(HighBit

Rate)audioformats.

Function

DIPSwitchPosition

1234

Auto-CopyEDID(Default)UpUpUp-

Fixed4K@120Hz4:4:410bitUpUpDown-

Fixed8K@30Hz4:4:410bitDownUpDown-

Fixed8K@60Hz4:2:010bitDownDownDown-

Fixed4K@60Hz4:4:48bitUpDownUp-

Fixed1080P@60HzUpDownDown-

InputaudioextractiontoS/PDIF

(Default)

---Up

ARCaudioextractiontoS/PDIF---Down

Troubleshooting

NoorPoorQualityPicture(snowornoisyimage)

•Verifythatpowerisbeingsuppliedtoalldevicesinthesystemandthattheyarepoweredon.

•VerifythatallHDMIconnectionsarenotlooseandarefunctioningproperly.

•Iftransmitting8K,verifythattheHDMIcablesusedare3Dor8Krated.

•EnsuretheEDIDoftheunitiscorrect.Seeforcorrectswitchpositions.EDIDDIPSwitchSettings

TroubleshootingTips:

WyreStormrecommendsusingacabletesterorconnectingthecabletootherdevicestoverifyfunctionality.
