O P E R A T I O N M A N U A L
©2018 EarthQuaker Devices LLC
<<< Power Requirements >>>
<<< Tech Specs >>>
• Current Draw: 81mA
• This device take a standard 9 volt DC power supply with a 2.1mm negative center barrel. We
always recommend pedal-specic, transformer-isolated wall-wart power supplies or multiple
isolated-output supplies. Pedals will make extra noise if there is ripple or unclean power.
Switching-type power supplies, daisy chains and non-pedal specic power supplies do not lter
dirty power as well and let through unwanted noise. DO NOT RUN AT HIGHER VOLTAGES!
• Input Impedance: 1M Ohm • Output Impedance: 500 Ohm
<<< Warranty >>>
This device has a limited lifetime warranty. If it breaks, we will x it. Should you encounter any
issues, please email info@earthquakerdevices.com.
www.earthquakerdevices.com
<<< Switching >>>
This device is true bypass and uses electronic relay-based switching. Audio will not pass
without power.
Up: Level control for the octave up.
Down: Level control for the octave down.
Choir: This control takes a mix of the
octave Up and octave setting Down
and regenerates it. The end result is an
additional 2 octaves up, 2 octaves down
and direct signal with a slight delay that
adds a “church organ” like feel. This
control only works if the octave Up and
octave Down are in use.
Lag: Delay control for the wet signal. Full
counterclockwise is minimal delay. Delay
time increases as it rotates clockwise.
Tone: Rolls off the high end as you dial it
counterclockwise.
Dire ct: Level control for the analog
dry signal.
1
2
3
4
5
6
Thanks for picking up the Organizer
™ from EarthQuaker Devices® brand effects pedals! The
Organizer is a polyphonic organ emulator designed to mimic the organ tones of yesteryear
crossed with the highly unique “Guitorgan”. It has a warm and very analog feel with a hint of
Leslie warble that is unlike other modern octave shifters. It is simple to dial in and tracks chords
as well as single notes perfectly all over the neck on both guitar and bass. Not only can the
Organizer be used on strings, it has been widely used on everything from vocals and synths to
horns and drums. If it makes sound, the Organizer can handle it!
The Organizer uses a mix of analog and DSP circuitry with true bypass switching and an all
analog dry signal path. It is hand made one at a time by a bunch of human beans in the beach
community of Akron, Ohio.
<<< Controls >>>
54 6
123
<<< Suggested Settings >>>
1967 Bass
Raindrops & Cobblestones
8th note staccato picking.
Bella Donna Gardens
Try with Tritones
Ascending / descending staccato picking.
