Wireless IEEE802.11 b/g/n

Broadband Router

* The EZMax Setup CD Wizard only supports Edimax wireless router.

BR-6524n

300Mbps Wireless-N Broadband Router

Edimax BR-6524n is a high speed 802.11n solution for home and small business. With advanced MIMO technology,

it’s wireless data transmission rate can be 12 times better (up to 300Mbps) and 6 times better coverage than a

standard 802.11g/b router. Simply connect BR-6524n to the Internet through a cable/xDSL modem. Also, it

supports major operating systems, Windows (98SE/ME/NT/2000/2003/XP/Vista), Mac OS X and Linux.

Edimax EZView and Remote Management

Edimax EZView is a new enhanced management system in BR-6524n which allows you to manage your router

locally or remotely from the Internet. UPnP compatible devices are automatically detected and information about

the device will be listed in the management interface of the router. You will be able to directly manage device

information like IP address, bandwidth control, open ports and DMZ.

Wi-Fi Protected Setup (WPS)

Press the WPS button to activate the wireless protection. One-Click WPS button helps you to setup a secure

wireless network in a minute.

Easy Setup with EZMax Multi-language Installation CD*

A unique 16-languages Setup Wizard is provided in the installation CD. You can setup the router to the Internet

within minutes by following the simple animated steps.

Flexibility with Detachable Antenna

BR-6524n incorporated with three detachable 3dBi RP-SMA antennas, meeting the expectation to change it to

high-gain antennas. Use in combination with Edimax EA-MARS (Antenna Re-locator) will eliminate dead spots

whilst bringing robust coverage.

FEATURES AND TECHNICAL SPECIFICATIONS

HARDWARE INTERFACE MANAGEMENT POWER ADAPTER

1 x RJ-45 10/100 Mbps WAN Port

4 x RJ-45 10/100 Mbps Ethernet LAN Ports

LED Indicators: Power, Wireless, WAN, LNK/ACT for LAN

3 x 3dBi PR-SMA Detachable Antenna

WPS / Reset Button

Supports Remote Management

Supports EZview Management

System Status and Security Log (Web Interface)

Firmware Upgradeable

DC 12V, 1A

WAN INSTALLATION MEMORY

Supports cable/xDSL modem

WAN protocol: PPPoE/Static IP/PPTP/Dynamic IP/

L2TP/Telstra Big Pond

16-languages EZMax Setup Wizard

12-languages User Interface

4 MB NOR Flash

16 MB SDRAM

SECURITY OUTPUT POWER &

RECEIVE SENSITIVITY

HUMIDITY &

TEMPERATURE

NAT/NAPT IP Sharing

64/128-bit WEP Encryption and WPA, WPA2 security

DHCP Server/Client

QoS

SPI Anti-Dos Firewall

11n: 16±1dBm, 11g: 16±1dBm

11b:18 1dBm±

11n (40MHz): -68dBm, 11n (20MHz):

-71dBm, 11g: -74dBm, 11b: -87dBm

10-90%

(Non-condensing)

0~45 Degree Celsius

FUNCTIONS DIMENSION CERTIFICATIONS

Supports AP , AP Client , Bridge , WDS and

Universal Repeater mode

Port Triggering for Special Applications

DDNS (DynDNS, TZO)

Virtual Server and DMZ

MAC/IP Filter and URL Blocking

Static Routing

UPnP

VPN Pass Through (IPSec/PPTP)

192 x 115 x 29 mm CE, FCC, WiFi

NETWORK SETUP DIAGRAM AND RELATED PRODUCTS

An example of how the BR-6524n can be setup:

•Connect the BR-6524n router to your Ethernet (RJ45) cable/xDSL modem.

•Connect a computer to the LAN port and setup the Internet connection by running the EZMax setup wizard.

•Share the Internet connection with other wired or wireless computers/devices.

•You can also share your printer using an Edimax print server.

Produktspecifikationer

Varumärke:	Edimax
Kategori:	Router
Modell:	BR-6524n
Certifiering:	CE, FCC, WiFi
Internminne:	16 MB
Antal användare:	12 användare (er)
Kompatibla operativsystem:	Windows 98SE, ME, NT, 2000, 2003, XP, Vista\nMac OS X\nLinux
xDSL-anslutning:	Nej
MAC-adressfiltrering:	Ja
Filtrering:	Ja
Flashminne:	4 MB
Spänning:	12 V
Antal LAN (RJ-45) anslutningar:	1
Produktstorlek (BxDxH):	192 x 115 x 29 mm
Temperatur vid drift:	0 - 45 ° C
Intervall för relativ operativ luftfuktighet:	10 - 90 %
Likströmsingång:	Ja
Stöd för garanterad tjänstekvalitet (QoS):	Ja
Ingående ström:	1 A
Externa anslutningar:	1 x RJ-45 10/100 Mbps WAN\n4 x RJ-45 10/100 Mbps Ethernet LAN\n3 x 3dBi PR-SMA Detachable Antenna
Maximal överföringshastighet:	0.3 Gbit/s
Beskrivning av uteffekt:	11n: 16 ±1dBm, 11g: 16 ±1dBm 11b: 18 ±1dBm, 11n (40MHz): -68dBm, 11n (20MHz):-71dBm, 11g: -74dBm, 11b: -87dBm
Stöder ISDN-anslutning:	Nej
