BIG MUFF PI WITH TONE WICK ER
With Enhanced Tone Processing
Congratulations on your purchase of the BIG MUFF with TONE WICKER The Pi !
BMPTW is a battery operated distortion pedal that maintains the legendary Big Muff
Pi sound while offering two powerful and dynamic tonal adjustmen that are unique ts
to any distortion or fuzz product found in the market today. The original B MUFF PI IG
sound is maintained while new tonal variations deliver edgy and aggressive sonic
possibilities.
- THEORY OF OPERATION -
The BIG MUFF with TONE WICKER is an effects pedal designed to deliver all of the Pi
sonic power of the legendary Big Muff Pi while providing user editing capabilities that
are unique to the Tone Wicker design. Wicker mode opens up the high frequency
bandwidth of your distortion sound delivering a top end that is new and exciting The .
Tone switch, when set to OFF, defeats yielding an the Big Muff’s Tone knob
extremely powerful distortion with a fire breathing new Big Muff Pi character.
- CONTROLS -
Sustain knob As in the original Big Muff Pi, adjusts the amount of sustain and –
distortion.
Tone Knob The Tone knob allows the musician to dial in just the right setting –
between deep bass and high treble.
Volume Knob The volume knob sets the overall output level of the effect –.
Wicker Switch Activate Wicker mode by flipping the Wicker switch up to the –ON
position where the high frequency bandwidth is opened up for a bright and clear top
end. Set the Wicker switch to OFF to obtain the classic Big Muff Pi sound.
Tone Switch The Tone switch allows the user to activate the Tone knob or to –
completely bypass the tone circuitry. When the Tone switch is set to ON, the Tone
knob is active, just like a standard Big Muff. When the Tone switch is set to OFF, the
Tone knob and all of its circuitry is bypassed. This setting yields a totally new Muff
distortion with a powerful drive and uncolored gain. High output with attitude. Please
Note: When the Tone switch is set to OFF, turning the Tone knob will produce no
change your sound. In addition, it is normal for the output volume of your Big Muff to
Pi with Tone Wicker to increase when moving the Tone switch from ON to OFF.
Status LED - When the LED is lit; the BMPTW effect active. When the LED is off, is
the BMPTW is in True Bypass mode. The Footswitch toggles between effect and
bypass modes.
INPUT Jack – This ¼” jack is the audio input to the BMPTW. The input impedance
presented at this jack is 130 k .
OUTPUT Jack audio output from the BMPTW. When the – This ¼” jack is the
BMPTW is in Bypass mode, the OUTPUT jack is connected directly to the INPUT jack.
9V Power Jack The Big Muff with Tone Wicker is battery powered. You may use –
an external AC Adapter power supply instead of the battery Connect the AC .
Adapter’s plug to the 9V Power Jack The power jack’s at the top of the BMPTW.
polarity is center negative. The BMPTW requires a clean 9VDC power supply at 50mA .
We recommend the Electro-Harmonix US96DC-200BI power supply.
- WARRANTY INFORMATION -
Please register online at http://www.ehx.com/product-registration or complete and
return the enclosed warranty card within 10 days of purchase. Electro-Harmonix will
repair or replace, at its discretion, a product that fails to operate due to defects in
materials or workmanship for a period of one year from date of purchase. This
applies only to original purchasers who have bought their product from an authorized
Electro-Harmonix retailer. Repaired or replaced units will then be warranted for the
unexpired portion of the original warranty term.
If you should need to return your unit for service within the warranty period, please
contact the appropriate office listed below. Customers outside the regions listed
below, please contact EHX Customer Service for information on warranty repairs at
info@ehx.com or +1- - -8300. USA and Canadian customers: please obtain a 718 937
Return Authorization Number A#) from EHX Customer Service before returning (R
your product. Include with your returned unit: a written description of the problem
as well as your name, address, telephone number, e-mail address, and RA#; and a
copy of your receipt clearly showing the purchase date.
United States & Canada
EHX CUSTOMER SERVICE
ELECTRO-HARMONIX
c/o NEW SENSOR CORP.
47 50- 33RD STREET
LONG ISLAND CITY, NY 11101
Tel: 718- - 937 8300
Email: info@ehx.com
Europe
JOHN WILLIAMS
ELECTRO-HARMONIX UK
13 CWMDONKIN TERRACE
SWANSEA SA2 0RQ
UNITED KINGDOM
Tel: +44 179 247 3258
Email: electroharmonixuk@virginmedia.com
This warranty gives a purchaser specific legal rights. A purchaser may have even
greater rights depending upon the laws of the jurisdiction within which the product
was purchased.
To hear demos on all EHX pedals visit us on the web at www.ehx.com
Email us at info@ehx.com
