Sida 1/4
C9
Organ Machine
Congratulations on your purchase of the Electro-Harmonix Organ Machine The C9 C9 .
transforms the tone of a guitar or keyboard into that of a convincing electric organ
yet is easy to use and play. Based on the sound engine found in the EHX B9 Organ
Machine, the C9 delves deeper into the sonic territory of classic organs covering a
vast array of memorable electric organ tones The s controls covering . C9 ha
percussive attack level, modulation speed, and both organ and dry volume.
WARNING: Your comes equipped with an Electro-Harmonix 9.6DC-200BI power supply C9
(same as used by Boss
®
& Ibanez
®
: 9.6 Volts DC 200mA). The requires 0mA at 9VDC with C9 10
a center negative plug. Using the wrong adapter or a plug with the wrong polarity may damage
your and void the warranty. C9
GETTING STARTED
Connect the supplied power adapter to the 9V power jack. Plug your instrument into
the INPUT jack; connect your amp to the ORGAN OUTPUT jack Set the DRY knob to .
minimum and all the other top row knobs to about mid position Select the preset .
named TONE WHEEL and step on the footswitch to turn on the LED. Play your
instrument and adjust controls to your liking. MOD controls modulation speed and
CLICK controls percussive click level.
DRY VOLUME KNOB
Controls the volume of the untreated instrument the ORGAN OUTPUT jack. at
ORGAN VOLUME KNOB
Controls the overall volume of the ORGAN preset.
MOD KNOB
MOD controls the . Modulation can be completely turned off speed of modulation
when MOD is set fully counterclockwise The type of modulation is contingent on the .
preset selected. The different types of modulation available are vibrato, tremolo and
chorus. See the preset descriptions for modulation type.
CLICK KNOB
CLICK controls It was design to simulate the harmonic percussive click level. ed
percussion effect on classic B3 and C3 organs. The click added to the very first is
note or chord played. The click will retrigger only when current notes have been
released and the amplitude falls below a threshold. For most presets, CLICK controls ir
parameters unique to the preset. See the preset descriptions for details.
BYPASS FOOTSWITCH
Press the BYPASS Footswitch to toggle the between buffered Bypass and Effect C9
mode. The status LED lights when in Effect mode.
DRY OUTPUT JACK
DRY outputs the signal present at the INPUT Jack through a buffer circuit. The dry
signal is outputted regardless if the is in Effect or Bypass mode. The DRY Volume C9
knob does not change the volume at the DRY Output jack.
ORGAN TPUT JACK OU
ORGAN outputs the mix set by the DRY and ORGAN controls.
PRESET DESCRIPTIONS
1. Tone Wheel - Classic tone wheel-esque organ sound.
MOD type:
Chorus.
CLICK sets level of click sound.
2. Prog – Paying homage to the massive sound of Keith Emerson of Emerson
Lake and Palmer.
MOD type:
Chorus.
adjusts the level of two CLICK
intervals: a fifth above and an octave below.
3. Compact - This preset imitates a sound similar to Ray Manzarek’s tone on
the Door’s “Light My Fire.”
MOD type:
Vibrato.
CLICK adjusts the level of
upper harmonics.
4. Shimmer - is preset is based on effect made popular by Brain Eno Th an
and Daniel Lanois. adjusts the attack time. controls the sustain MOD CLICK
amount.
5. Lord Purple – Our salute to the Jon Lord-ish type organ sound of Deep
Purple. The ORGAN level controls the level of one set of 3 drawbars.
MOD
Type: Chorus.
CLICK adjusts the level of a second set of 3 drawbars.
6. Mello Flutes – A tribute to the classic Mellotron flute tape sound of The
Beatles’ “Strawberry Fields Forever.” song
MOD Type: Vibrato.
CLICK
adjusts the depth of the vibrato.
7. Blimp - Led Zeppelin type sound
. MOD Type: Chorus.
CLICK adjusts the
level of upper harmonics.
8. Press Tone – EHX’s nod to the great organ sound found on ’ The Beatles
song “Let It Be.”
MOD type:
Chorus.
CLICK sets level of click sound.
9. Telstar - Envisions the legendary sound of a Clavioline as used on The
Tornadoes song “Telstar.”
MOD Type: Vibrato.
CLICK adjusts the level of
upper harmonics.
Note: On presets 2, 3, 5 and 7; the CLICK knob is a volume control that works
independent of the main ORGAN volume knob. ly
NOTES AND SPECIFICATIONS
• C9 has buffered bypass.
• Input impedance is 1M .
• Output impedance for both output jacks is 500 .
• Current draw of the is mA. C9 100
- WARRANTY INFORMATION -
Please register online at http://www.ehx.com/product-registration or complete and
return the enclosed warranty card within 10 days of purchase. Electro-Harmonix will
repair or replace, at its discretion, a product that fails to operate due to defects in
materials or workmanship for a period of one year from date of purchase. This
applies only to original purchasers who have bought their product from an authorized
Electro-Harmonix retailer. Repaired or replaced units will then be warranted for the
unexpired portion of the original warranty term.
If you should need to return your unit for service within the warranty period, please
contact the appropriate office listed below. Customers outside the regions listed
below, please contact EHX Customer Service for information on warranty repairs at
info@ehx.com or +1- - -8300. USA and Canadian customers: please obtain a 718 937
Return Authorization Number (RA#) from EHX Customer Service before returning
your product. Include with your returned unit: a written description of the problem
as well as your name, address, telephone number, e-mail address, and RA#; and a
copy of your receipt clearly showing the purchase date.
United States & Canada
EHX CUSTOMER SERVICE
ELECTRO-HARMONIX
c/o NEW SENSOR CORP.
47-50 33RD STREET
LONG ISLAND CITY, NY 11101
Tel: 718- - 937 8300
Email: info@ehx.com
Europe
JOHN WILLIAMS
ELECTRO-HARMONIX UK
13 CWMDONKIN TERRACE
SWANSEA SA2 0RQ
UNITED KINGDOM
Tel: +44 179 247 3258
Email: electroharmonixuk@virginmedia.com
This warranty gives a purchaser specific legal rights. A purchaser may have even
greater rights depending upon the laws of the jurisdiction within which the product
was purchased.
To hear demos on all EHX pedals visit us on the web at www.ehx.com
Email us at info@ehx.com
