Sida 1/4
1
Datasheet
Powered by EnGenius Single Port Power-
over Ethernet (PoE) adapter soluon is ideal -
for installers to deploy PoE devices scalable,
and to reduce maintenance cost and labor
fee.
The ideal soluon could assist installers to solve the limitaon
in designing networks is the availability of power source. The
EnGenius PoE adapter allows delivery of both data and power
to compable Access Points or device over a single Ethernet
cable, allowing deployment of them exactly when users
needed to provide the best wireless coverage and at much
lower installaon cost.
Besides built in networking facility, EPA series is also equipped -
with short circuit and overload protecon to assure the -
securable and reliable connecon for Access Points or other
PoE devices. By sending direct current (DC) output, Ethernet
terminals which need more power such as wireless LAN high
power device, IP media center, and web camera are powered
remotely.
Features
> Scalable deployment by powering devices
from up to 100 meter (328 feet) remote end-
> Signicantly reduce maintenance cost and
labor fee
Physical Interfaces
LED INDICATORS
AC Connector
POE
LAN
Reset
(For models only)GR
2
Technical Specicaons Single Port Power over Ethernet (PoE) Adapter- -
Model EPA2406FP EPA2406GP EPA2406GR EPA2410GP
Power Specicaon
Input Voltage 100V~240V AC
Input Current 0.4A @ 120V AC 0.4A @ 120V AC 0.4A @ 120V AC 0.7A @ 120V AC
AC Input Frequency 60Hz 50-
Max. Output Power 14.4W 14.4W 14.4W 24W
Power Line Pin4(Vdc+)&Pin5(Vdc+); Pin7(Vdc )&Pin8(Vdc ) - -
Data Specicaons
Ethernet Ports Std. 10/100 Mbit/s 10/100/1000 Mbit/s
Data Lines Pin1(Rx+)&Pin2(Rx ); Pin3(Tx+)&Pin6(Tx ) - -
Protecon Level
Surge Protecon L L: 2KV; L G: 4KV - - L L: 1KV; L G: 2KV - -
ESD Contact 4KV; Air: 8KV
Other Protecon Over voltage and over current protecon; Short circuit protecon - - -
Physical Interfaces & Indicators
Ethernet Ports 1 x 10/100/1000 Data input; 1 x 10/100/1000 Data & power output
AC Connector 1 x IEC 320C6 AC connector (US, EU, UK, AU)
LED Indicator Power on : Green
Mechanical & Environment
Dimension 100mm x 58.4 mm x 33.4 mm (3.9” x 2.27” x 1.3”)
Weight (Adapter On-
ly) 112g (3.95oz) 112g (3.95oz) 112g (3.95oz) 144g (5.08 oz)
Temperatures Storage : 20 ~ 70°C ( 4 ~ 158 °F ), Operaon : 0 ~ 40°C (42 ~ 140 °F ) - -
Compliance Regulatory
CB - IEC 60950 1: 2005+A1+A2
UL -UL 60950 1 2
nd
FCC FCC Subpart15 B
CE EN 55032:2012/AC:2013, EN 55024: 2010
RCM AS/NZS60950.1: 2011/Amdt 1: 2012
Warranty
1 year hardware warranty
3
Technical Specicaons Single Port Power over Ethernet (PoE) Adapter- -
Model EPA5006GP EPA5006GR EPA5006GAT EPA5012GP
Power Specicaon
Input Voltage 100V~240V AC
Input Current 0.8A @ 120V AC 0.8A @ 120V AC 0.8A @ 120V AC 1.12A @ 120V AC
AC Input Frequency 60Hz 50-
Max. Output Power 32.8W 32.8W 30W 60W
Power Line Pin4(Vdc+)&Pin5(Vdc+); Pin7(Vdc )&Pin8(Vdc ) - -
Data Specicaons
Ethernet Ports Std. 10/100/1000 Mbit/s
Data Lines Pin1(Rx+)&Pin2(Rx ); Pin3(Tx+)&Pin6(Tx ) - -
Protecon Level
Surge Protecon L L: 2KV; L G: 4KV - -
ESD Contact 4KV; Air: 8KV
Other Protecon Over voltage and over current protecon; Short circuit protecon - - -
Physical Interfaces & Indicators
Ethernet Ports 1 x 10/100/1000 Data input; 1 x 10/100/1000 Data & power output
AC Connector 1 x IEC 320C6 AC connector (US, EU, UK, AU)
LED Indicator Power on : Green
Mechanical & Environment
Dimension 100mm x 58.4 mm x 33.4 mm (3.9” x 2.27” x 1.3”)
Weight (Adapter On-
ly) 144g (5.08 oz) 144g (5.08 oz) 154g (5.44 oz) 186g (6.56oz)
Temperatures Storage : 20 ~ 70°C ( 4 ~ 158 °F ), Operaon : 0 ~ 40°C (42 ~ 140 °F ) - -
Compliance Regulatory
CB - IEC 60950 1: 2005+A1+A2
UL -UL 60950 1 2nd
FCC FCC Subpart15 B
CE EN 55032:2012/AC:2013, EN 55024: 2010
RCM AS/NZS60950.1: 2011/Amdt 1: 2012
Warranty
1 year hardware warranty
