LX LCD Accessory Arm
User's Guide - English
Guía del usuario - Español
Manuel de l’utilisateur - Français
Gebruikersgids - Deutsch
Benutzerhandbuch - Nederlands
Guida per l’utente - Italiano
Användarhandbok - svenska
: 本語
用户指南 :
Includes
Constant Force
Technology
ENGLISH
ASSEMBLY INSTRUCTIONS
For the latest User Installation Guide please visit: www.ergotron.com
CAUTION! The LX Arm Accessory is designed to be used only
with the 45-295 LX Desk Mount LCD Arm, Tall Pole product, with
a total of two (2) arms per pole. Using the LX Arm Accessory with
any other product or in quantities greater than two (2) arms per
pole may create an unstable situation resulting in equipment
damage and/or personal injury.
2 of 9
888-97-387-G-00 rev.B• 04/15
A B C D
1
2
3
4
M4 x 10mm
4x
M4 x 10mm
4x
4mm
1x
1x 1x
M3 x 6mm
70°
180°
360°
180°
13"
(330 mm)
1x 1x
2x
2.5mm 1x
< 4.5” (114 mm)
8.5” (216 mm)
5 - 25 lbs*
(2.3 - 11.3 kg)
1x
1x
1x 4x
10 - 24 x 1/2
1/8”
ENGLISH
Components
Tools Needed
* The lower most range of motion for vertical lift is
decreased up to 4.5” (114 mm) when arm is adjusted to
hold over 20lbs (9 kgs).
3 of 9
888-97-387-G-00 rev.B• 04/15
1
WARNING
M4 x 10mm
M4 x 10mm
4x
4x
M3 x 6mm
1x
ENGLISH
WARNING! Stored Energy Hazard: The arm mechanism is under tension and will move up rapidly, on its own, as
soon as attached equipment is removed. For this reason, DO NOT remove equipment unless the arm has been
moved to the highest position! Failure to follow this instruction may result in serious personal injury and/or
equipment damage!
