Sida 1/44

To reduce the impacts on global warming, the packaging materials of this product

are recyclable and reusable. GIGABYTE works with you to protect the environment.

For more product details, please visit GIGABYTE's website.

B550 GAMING X

User's Manual

Rev. 1001

12ME-B55GMX-1001R

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specications and features in this manual may be made by GIGABYTE without

prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or

published in any form or by any means without GIGABYTE's prior written permission.

 In order to assist in the use of this product, carefully read the User's Manual.

 For product-related information, check on our website at: https://www.gigabyte.com

Identifying Your Motherboard Revision

The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0"

means the revision of the motherboard is 1.0. Check your motherboard revision before updating

motherboard BIOS, drivers, or when looking for technical information.

Example:

- 3 -

Table of Contents

B550 GAMING X Motherboard Layout ............................................................................4

Chapter 1 Hardware Installation .....................................................................................5

1-1 Installation Precautions .................................................................................... 5

1-2 Product Specications ...................................................................................... 6

1-3 Installing the CPU ............................................................................................ 9

1-4 Installing the Memory ....................................................................................... 9

1-5 Installing an Expansion Card ......................................................................... 10

1-6 Back Panel Connectors .................................................................................. 10

1-7 Internal Connectors ........................................................................................ 12

Chapter 2 BIOS Setup ..................................................................................................20

2-1 Startup Screen ............................................................................................... 20

2-2 The Main Menu .............................................................................................. 21

2-3 Favorites (F11) ............................................................................................... 22

2-4 Tweaker .......................................................................................................... 23

2-5 Settings .......................................................................................................... 26

2-6 System Info. ................................................................................................... 32

2-7 Boot ................................................................................................................ 33

2-8 Save & Exit ..................................................................................................... 36

Chapter 3 Appendix ......................................................................................................37

3-1 Conguring a RAID Set .................................................................................. 37

3-2 Drivers Installation .......................................................................................... 39

Regulatory Notices .................................................................................................... 40

Contact Us ................................................................................................................ 44

Produktspecifikationer

Varumärke:	Gigabyte
Kategori:	moderkort
Modell:	B550 Gaming X
Vikt:	160 g
Bredd:	57 mm
Djup:	84 mm
Internationell säkerhetskod (IP):	IP20
Wi-Fi:	Nej
Maximal upplösning:	4096 x 2160 pixlar
Antal HDMI-portar:	1
HDCP:	Ja
HDMI-version:	2.1
Hållbarhetscertifikat:	RoHS
Uteffekt:	25 W
Maximalt internminne:	128 GB
Ljudutgångskanaler:	7.1 kanaler
Utström:	0.7 A
Spännande:	36 V
Komponent för:	PC
Kompatibla processorer:	AMD Ryzen 3 3rd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Minnestyper som stöds:	DDR4-SDRAM
AC-ingångsspänning:	90 - 264 V
Typer av lagringsenheter som stöds:	HDD & SSD
Antal minnesplatser:	4
BIOS-typ:	UEFI AMI
ACPI-version:	5.0
Obuffrat minne:	Ja
processortillverkare:	AMD
Windows-operativsystem som stöds:	Windows 10 x64
Typ av ethernet-gränssnitt:	Gigabit Ethernet
Antal LAN (RJ-45) anslutningar:	1
processorsockel:	Uttag AM4
Kabel inkluderad:	SATA
Antal PS/2-portar:	1
Nätverksansluten (Ethernet):	Ja
Antal USB 2.0 anslutningar:	2
RAID-nivåer:	0, 1,10
Minnesplatser, typ:	DIMM
Minneskanaler:	Dubbla kanaler
Minnets hastigheter:	2133,2400,2667,2933,3200,3333,3666,4000,4400,4600,4733 MHz
Max antal processorer:	1
USB 2.0 anslutning:	2
ATX strömkontakt (24-pin):	Ja
Kontakter på framsidan:	Ja
TPM-anslutning:	Ja
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	3
Antal USB 3.2 Gen 2 (3.1 Gen 2) typ A-portar:	1
BIOS minnesstorlek:	256 mbit
Moderkort, chipsetfamilj:	AMD
Moderkortets chipset:	AMD B550
Moderkort formfaktor:	ATX
Antal M.2 (M)-platser:	2
Harmonized System (HS)-kod:	84733020
Medföljande programvara:	Norton Internet Security (OEM)\nRealtek 8118 Gaming LAN Bandwidth Control Utility
Antal DVI-D anslutningar:	1
Drivrutiner medföljer:	Ja
Lagringsenhetsgränssnitt som stöds:	SATA III
Ljudchipp:	Realtek ALC887
Klar CMOS-bygel:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-anslutningar:	1
Antal SATA III kontakter:	4
CPU-fläktsanslutning:	Ja
Antal anslutningar för fläktar:	3
12V-kontakt:	Ja
Ljudanslutning på framsidan:	Ja
RGB LED stiftlist:	Ja
PCI Express x1 (Gen 3.x)-kortplatser:	3
PC hälsoövervakning:	FAN, Temperature, Voltage
Maximalt minne på grafikkort:	16000 MB
PCI Express x16 platser:	2
Systemhantering BIOS (SMBIOS)-version:	2.7
Version av Desktop Management Interface (DMI):	2.7
