Operating Instructions

Room temperature controller clock with cooling function

2370 ..

BA_23701290.fm Seite 1 Donnerstag, 26. September 2013 11:14 11

Table of contents

Normal view in the display...........................................................................3

Basic operation of the room temperature controller .............................3

The individual displays and buttons.......................................................3

Device description .......................................................................................4

Starting up the room temperature controller ...............................................4

Prolonging the heating phase (party function).............................................5

Terminating the party function...............................................................5

Changing over to the lowering temperature (economy button)...................5

Switching for brief periods to the lowering temperature.......................5

Permanently switching over to lowering temperature...........................5

Deactivating the lowering temperature .................................................5

Setting the individual temperature...............................................................6

Settings in the program menu .....................................................................6

Starting the program menu ...................................................................6

Setting the date and time – Uhr menu item ..........................................7

Modifying the temperature steps – tEMP menu item ...........................8

Modifying the time program – ProG menu item....................................9

Modifying the switching time................................................................9

Deleting a switching time ....................................................................10

Aborting the settings at the time program ..........................................11

Setting the holiday program – UrLb menu item ..................................11

Setting the holiday period....................................................................11

Activating/deactivating the anti-freeze function – FrSt menu item .....12

Selecting the operating mode – ModE menu item..............................13

Locking buttons .........................................................................................13

Cleaning the room temperature controller.................................................13

Warranty ....................................................................................................14

BA_23701290.fm Seite 2 Donnerstag, 26. September 2013 11:14 11

Normal view in the display

Basic operation of the room temperature controller

Use + and - to set values such as the time or the temperature.

Confirm the set values with S.

If you do not press the S button after carrying out a setting, the display

changes automatically back to normal display 5 seconds after last pressing

a button. Changes to the respective values are not accepted in this case.

The P button can be used at any time to return to the normal time pro-

gram.

The individual displays and buttons

1 The current weekday is displayed here.

2 Symbol for the "Time program" operating mode.

3 Symbol for the "Comfort temperature" operating mode.

4 Symbol for the "Lowering temperature" operating mode.

5 Symbol for the "Anti-freeze temperature" operating mode.

6 The current operating mode is indicated here by means of triangles.

7 The ranges set for the comfort temperature in the time program are

displayed here.

8 - or button, also called the economy button.

9 P button.

10 S button.

11 + or button, also called the party button.

12 The time is displayed here.

You can have this display changed to the temperature display for

example by the installer.

13 This indicates whether heating (▲) or cooling (▼) is being imple-

mented.

14 Further information on the settings being carried out is displayed

here: e.g. H if you set the time.

BA_23701290.fm Seite 3 Donnerstag, 26. September 2013 11:14 11

Produktspecifikationer

Varumärke:	Gira
Kategori:	Termostat
Modell:	237003
Måttenhet:	°C
Minnesfunktion:	Nej
Driftspänning:	230 V
Fjärrkontroll ingår:	Nej
Programmerbar:	Ja
Temperatursensor:	Ja
Smart termostat:	Ja
Bakgrundsbelyst skärm:	Nej
Produktens färg:	Vit
Internationellt skydd (IP) kod:	IP30
Displaytyp:	Digital
Strömkälla:	AC
Antal:	1
Kylning:	Ja
Temperaturintervall för börvärde:	10 - 40 ° C
Temperaturområde (T-T):	0 - 50 ° C
Manuell temperaturjustering:	Ja
Schemaläggningsfunktion:	Ja
Maximal växlingsström:	8 A
