07/07/2022 Models 3602/3602F Page 1 of 12
1455 Kleppe Lane Sparks, NV 89431-6467 (775) 359-4712 Fax (775) 359-7424
E-mail:
haws@hawsco.com website: www.hawsco.com
No. 0510001187 (3)
MODELS 3602 & 3602F (with Filter)
Outdoor Drinking Fountain
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
LIMITED WARRANTY
HAWS warrants that all of its products are guaranteed against defective material or poor workmanship for
a period of one year from the date of shipment. The foregoing notwithstanding, HAWS warrants certain
specific products or components thereof for an adjusted period. A list of these excepted products and
components and a description of their respective warranty terms may be found here:
www.hawsco.com/warranty. HAWS’ liability under this warranty shall be discharged by furnishing without
charge F.O.B. HAWS factory any goods, or part thereof, which shall appear to the Company upon
inspection to be of defective material or not of first-class workmanship, provided that a claim is made in
writing to Company within a reasonable period after receipt of the product. Where claims for defects are
made, the defective part or parts shall be delivered to the Company, prepaid, for inspection. HAWS shall
not be liable for the cost of repairs, alterations or replacements, or the labor required to implement them, or
for any expense connected therewith made by the owner or owner’s agents, except upon written authority
from HAWS. HAWS shall not be liable for any damages caused by defective materials or poor
workmanship, except for replacements, as provided above. Buyer agrees that HAWS has made no other
warranties either express or implied in addition to those above stated, except that of title with respect to
any of the products or equipment sold hereunder and that HAWS shall not be liable for general, special,
incidental, or consequential damages claimed to arise under the contract of sale.
Equipment manufactured by HAWS is warranted to function if installation and maintenance instructions
provided are adhered to. The units also must be used for the purpose for which they were intended. Any
HAWS emergency equipment is intended to supplement first-aid treatment. Due to widely varying
conditions, HAWS cannot guarantee that the use of this emergency equipment will prevent serious injury
or the aggravation of existing or prior injuries.
EXCEPT AS EXPRESSLY STATED HEREIN, HAWS HEREBY DISCLAIMS ALL WARRANTIES,
WHETHER EXPRESS OR IMPLIED, ARISING BY LAW OR OTHERWISE, INCLUDING WITHOUT
LIMITATION, ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. THIS WARRANTY MAY NOT BE MODIFIED OR EXTENDED WITHOUT THE
WRITTEN CONSENT OF HAWS. REMEDIES AND REPLACEMENTS STATED HEREIN ARE
EXCLUSIVE. IN NO EVENT SHALL HAWS BE LIABLE FOR ANY SPECIAL, PUNITIVE,
CONSEQUENTIAL OR INCIDENTAL DAMAGES TO ANY PERSON INCLUDING BUT NOT LIMITED
TO DAMAGES FOR LOSS OF USE OR PROFITS, SUBSTITUTE PRODUCTS OR COSTS, PROPERTY
DAMAGE, OR OTHER MONETARY LOSS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297
07/22 Models 3602/3602F Page 2 of 12
RECOMMENDED TOOLS:
- Measuring Tape
- PVC Pipe Cutter
- Plastic Tubing Cutter
- PVC Solvent Weld Glue
- ¼” Bit-Holding Screwdriver
- Level
- 10” Pipe Wrench
- Adjustable Plier
- 1/8 and 5/32 Tamper Resistant Hex Bits (Supplied)
- 9/16” and 5/8” Box/Open Combination Wrenches, 8” Max Length
- 3/8” Socket Wrench/Rachet, 8” Max Length
- 9/16” Deep Socket
- 15/16” Socket
LOCATION OF UNIT: The Model 3602/3602F (with Filter) Fountain can be installed and
assembled to be ADA accessible by first locating the pedestal base on a hardscape with
dimensions that comply with your local, state, and federal codes regarding clear floor space
and pedestrian protection area. Refer to the last page of this document for more information.
When the right pedestal arm is installed in the high orientation, the height dimensions shown
on the model specification sheet meet current Federal Americans with Disabilities Act (ADA)
wheelchair requirements. When a fountain is installed on top of the pedestal, the height
dimensions shown on the model specification sheet meet current ADA standing height
requirements. When installing this unit, local, state and federal (including ADA) codes must be
adhered to. If height other than shown is required, then dimensions must be adjusted
accordingly.
ATTENTION: For model 3602F (model with Filter), the Operating Temperature Range for the
6477 Filter Kit Assembly (Required - supplied separately) is 40° F - 100° F (4.4° C – 37.8° C).
SUPPLY LINE: Model 3602 – The minimum recommended line size is 1/2“IPS with 30-90 psi
(2-6 ATM) flowing pressure. Where sediment or mineral content is a problem, an inlet filter is
recommended. Model 3602F (with Filter) – The minimum recommended line size is 1/2“IPS
with 40-90 psi (2.76-6 ATM) flowing pressure.
PLUMBING CONNECTIONS: Model 3602 – Water supply inlet connection is a 3/8“O.D.
compression fitting. Waste outlet is 1-1/2” PVC pipe. Model 3602F – Water supply inlet and
outlet connection (for Filter) is a 3/8“O.D. push-in type fitting. Waste outlet is 1-1/2” PVC pipe.
Plumbing connections will vary depending on how each model is configured during assembly.
Please consult the installation drawings below for supply and waste fitting arrangements and
assembly for your specific model.
MAINTENANCE: Models 3602 & 3602F Periodically clean the pushbutton valve strainer.
Refer to 5874 Series Valve Operation and Maintenance Manual for more information. Model
3602F – Filter replacement to occur at 1 year maximum or 3,000 gallons maximum, whichever
comes first. Replace filter per Filter Replacement instructions listed on model 6477 Operation
& Maintenance Manual.
