Sida 1/2
FLEX CONDUIT
1/2" UNIONS
(BY OTHERS
RECOMMENDED)
6"MIN.
152mm
STRAIGHT
FOR MODEL 9001.5
OR 1/2" IPS
STRAIGHT
6"MIN.
152mm
DIRECTION
NOTE FLOW
ARROW
SHOWER
OR1-1/4" UNIONS
FOR MODEL 9001.5
DO NOT DISASSEMBLE OR ROTATE
THIS ASSEMBLY AT ANY JOINT
A
S DAMAGE WILL OCCUR
1-1/4 IPS
WATER SUPPLY
1. THE SIGNAL FROM THE PINK WIRE WILL BE SUPPLY VOLTAGE WHEN NO
WATER IS FLOWING AND ZERO VOLTAGE WHEN THE FLOW SWITCH AND
LOCAL ALARM ARE ACTIVATED. IF A REMOTE ALARM IS NOT USED,
THE PINK WIRE MUST BE INSULATED AT ITS FREE END. LEAVING THE
TWO CRIMP TERMINALS (SUPPLIED) CONNECTED WILL DO THIS.
2. INSTALLER MUST USE A THREAD SEALANT, SUCH AS APPLETON
TLC3, RECOMMENDED FOR USE ON ELECTRICAL COMPONENTS ON
ALL ELECTRICAL NPT CONNECTIONS.
POWER SOURCE
POWER SOURCE
NC
FLOW SWITCH
(DPDT)
LOAD
(CUSTOMER)
(BLK)
(PURPLE)
GROUND
(RED)
(PINK)
(GRN)
HOT
NO
COM
NC
NO
COM
(WHITE)
NEUTRAL
FL LT
(WHT)
(BLK)
(BLK)
(RED)
HORN
CUSTOMER 120 VAC
(CUSTOMER)
SEE SHEET 2
FOR CLAMP ASSEMBLY DETAIL
(REF)
(RED)
SWITCH
(13")
APPROVED:
DRAWN:
PART NUMBER
SCALE:
SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved.
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
C
R
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
(775) 359-4712 FAX (775) 359-7424
E-MAIL: HAWS@HAWSCO.COM
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
CH
01/09/01
30
0002080202.D
9001/9001.50 ALARM
1:1
12
FV
11/03/16
VWC
INSTALLATION
5149
2016
VWC
(3-5/8")
1 SNAP CLAMP TO BE INSTALLED FIRST FOR VERTICAL SUPPORT.
2 SCREWS INSTALLED FROM FRONT, WITH BOX DOOR OFF.
3 NUTS TO BE INSTALLED TO A TORQUE OF 12 IN-LBS MAX.
2X PIPE CLAMP
4X WASHER
SNAP CLAMP
4X HEX NUT
4X 8-32 SCREW
4X WASHER
BOX DOOR
2
2
3
1
LID TO BE INSTALLED
TO 3 IN/LBS TORQUE
MAX PIPE SIZE
Ø1 5/8"
APPROVED:
DRAWN:
PART NUMBER
SCALE:
SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved.
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
C
R
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
(775) 359-4712 FAX (775) 359-7424
E-MAIL: HAWS@HAWSCO.COM
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
CH
01/09/01
30
0002080202.D
9001/9001.5 ALARM
1:1
22
FV
11/03/16
VWC
INSTALLATION
5149
2016
VWC
