CLEAN VALVE SEAT AND WASHER THOROUGHLY, LUBRICATE
SEAT WASHER
SCREW
'O' RING
SPRING
'O' RING WITH 'O' RING LUBE BEFORE REASSEMBLING.
CAM OPERATOR
'O' RING FOR CAM
OPERATOR STEM
HOLDER WASHER
DESCRIPTION
1
4
8
7
6
5
1
1
1
1
QUANTITY
3
2
1
ITEM NO.
1
2
1
SEAT & OPERATOR
STEM ASSEMBLY DETAIL
6
5
4
1.265
.005
±
3
7
8
STEM ASSEMBLY DETAIL
SEE SEAT & OPERATOR
1
2
6.25 GPM
FLOW
CONTROL
APPROVED:
DRAWN:
PART NUMBER
DRAWING NO.
SCALE:
SHEET
OF
REV
DRAWING TYPE:
SIZE: A
BY:ECN NO.
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved.
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
C
R
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
(775) 359-4712 FAX (775) 359-7424
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
F. VASQUEZ
05/13/93
10772A00
5
0002080341
SP248
VALVE SQUEEZE HANDLE
1:4
11
HM
INSTALLATION
4843
2013
VALVE REPAIR DETAIL
MODEL VRKSP248
OPTIONAL
SP248
