•Removable air filter protects condenser and makesfor

easier cleaning

•Environmentally friendly R290 hydrocarbon refrigerant

•Stainless steel exterior front, sides and top

•Stainless steel interior sides and back with stainless

steel interior floor

•Solid state digital controller with temperature alarms

and LED display (Fahrenheit or Celsius)

•Cabinet and drawers are insulated with 2” CFC free

foamed in place polyurethane

•Stainless steel exterior drawer with stainless steel

interior

•Drawers will accommodate (3) 12” x 20” x 6” deep

pans (pans by others)

•Drawer module frames, acetal rollers and drawer stops

are formed of heavy duty stainless steel all welded

construction and securely fastened in the cabinet

•Drawers are equipped with finger cut-outs for easy

removal of pans

•Extruded aluminum flush mount drawer handles

•Magnetic drawer gasket is easily removable for

cleaning

•Removable stainless steel end panel for access to

refrigeration system

•E-coated evaporator coil

•Energy efficient automatic hot gas condensate

evaporator

•Standard with (8) 4" casters all with brakes (factory-

installed)

•10 ft. cord and plug

CR110B(-L)

11/07/25

Item # 13493B

CR110B(-L)

110” Low-Profile Refrigerated Chef Base

Item #:

Project:

Qty:

AIA#:

618 Hwy, 74 S., Peachtree City, GA 30269 | TEL 800-438-6087 | FAX 800-345-1325 | www.hoshizakiamerica.com

© HOSHIZAKI AMERICA, INC.

Heavy duty 16 gauge stainless steel top

with marine edge (front/rear), drip

edge (sides)

Ceramic heat shield integral to top

protects food from high heat

2000 pound capacity provides sturdy

base for cooking equipment

Hoshizaki reserves the right to change specifications without notice.

W x D x H

110.5” x 32.25” x 26”*

*to work surface with 4” casters

Item #:

Project:

Qty:

AIA#:

Features

Options

Dimensions / Capacity

Electrical / Refrigeration

Interior Storage Capacity (CF) (AHAM)

Overall Width x Depth

(including 1” bumper)

Overall Height (including 4” casters)

Height To Work Surface (including 4” casters)

Depth with Drawer Fully Open (including 1” rear bumper)

Drawer Opening Width

Drawer Opening Height

Pan Capacity

(12” x 20”) / per drawer

Maximum Pan Depth

Maximum Load Capacity

Crated Shipping Weight

Crated Length x Width x Height

Voltage

HACR Breaker

Electrical Connection

(NEMA)

Voltage Range

Ambient Temp. Range

Control Setpoint Range

Amperage

Energy Consumption

(kWh/day) @ASHRAE

Heat Rejection(BTU/Hr.) @NSF

Approx. Nominal Compres. BTU/HR (HP)

Refrigerant / Charge Amount (oz)

22.78 ft

3

110.5” x 33.25”

27”

26”

55.75”

38.5”

7”

12

total / 3 per drawer

6”

2000 lbs.

671 lbs.

112” x 34.5” x 30.5”

115/60/1

15.0 Amps

5-15P

104-126

45° to 100°F

28° to 45°F

3.0

2.25

482

1354(1/5HP)

R290(4.2 oz)

Two-Section CR110B(-L)

Two-Section CR110B(-L)

®

If GFCI is required, a GFCI breaker MUST be used in lieu of GFCI receptacle

YR

LABOR

PARTS

COMPRESSOR

Seven year warranty

on labor, parts, and

compressor. Valid in

United States, Canada,

Puerto Rico and U.S.

Territories.

For more information, please visit

hoshizakiamerica.com/support/warranty/

Drawer divider bars (Left to Right)- HS-4007

Drawer divider bars (Front to Back) - HS-5691

Stainless steel drawer liners - HS-5745

CR110B - Condenser on Right Side

CR110B-L - Condenser on Left Side

CR110B-L

CR110B
