INSTRUCTION MANUAL
GM800
MF/HF MARINE TRANSCEIVER
i
Thank you for choosing this Icom product. This
product is designed and built with Icom’s state of the
art technology and craftsmanship. With proper care,
this product should provide you with years of trouble-
free operation.
The GM800 has Class A DSC functions for Distress
alert transmission and reception, as well as general
DSC calls (Individual call, Group call, Geographic
Area call, Position Request call, Polling Request call,
and Test call).
IMPORTANT
READ ALL INSTRUCTIONS carefully and
completely before using the transceiver.
SAVE THIS INSTRUCTION MANUAL — This
instruction manual contains important operating
instructions for the GM800.
This instruction manual includes some functions that
are usable only when your dealer preset them.
Ask your dealer for details.
IN CASE OF EMERGENCY
If your vessel requires assistance, contact other
vessels and the Coast Guard by sending a Distress
call using Digital Selective Calling (DSC) on an
emergency frequency.
When immediate help is needed:
1. While lifting the key cover, hold down
[DISTRESS] for 3 seconds until you hear 3
short countdown beeps and 1 long beep sound.
2.
Wait for an Acknowledgment from another station.
3. After the Acknowledgment is received, hold
down [PTT] on the microphone and send the
following information.
1 “MAYDAY, MAYDAY, MAYDAY.”
2 “THIS IS . . . . . . . . (name of vessel).”
3 “LOCATED AT . . . .(vessel’s position).”
4 Give the reason for the Distress call.
5 Explain what assistance you need.
6 Give additional information about your vessel:
• Type
• Length
• Color
• The number of people on board
EXPLICIT DEFINITIONS
WORD DEFINITION
RDANGER!
Personal death, serious injury or an
explosion may occur.
RWARNING!
Personal injury, re hazard or
electric shock may occur.
CAUTION
Equipment damage may occur.
NOTE
If disregarded, inconvenience only.
No risk of personal injury, re or
electric shock.
NOTE: This transceiver receives the frequency
range 30 kHz ~ 500 kHz in the J3E mode, but it
has not been tested and Icom does not warrant
the operation in this frequency range. Thus this
transceiver does not conform to the permission of
the frequency range 415 kHz ~ 526.5 kHz which is
permitted by the ITU Radio Regulations [3].
To stabilize the output frequency:
±10 Hz frequency stability requires a warming up time
period.
The warming up time period is within 30 minutes after
turning ON the transceiver’s main power, and it differs
depending on the output temperature.
INSTALLATION NOTE
Installation:
The installation of this equipment should be made in
such a manner as to respect the EC recommended
electromagnetic eld exposure limits. (1999/519/EC)
The maximum RF power available from this device,
including tuner is 125 watts. The antenna should be
installed as high as possible for maximum efciency
and the installation height should be at least 3 meters
above any accessible position. In the case where an
antenna cannot be installed at a reasonable height,
then the transmitter should neither be continuously
operated for long periods if any person is within a
distance of 3 meters of the antenna, nor operated at
all if any person is touching the antenna.
It is recommended that antenna of a maximum gain
of 0 dBd is used. If higher gain antenna are required
then please contact your Icom distributor for revised
installation recommendations.
Operation:
The exposure to RF electromagnetic eld is only
applicable when this device is transmitting. This
exposure is naturally reduced due to the nature of
alternating periods of receiving and transmitting.
Keep your transmissions to the minimum necessary.
