PACKAGE CONTENTS
• 4-Port USB switch
• USB 3.0 cables (2) (USB 3.0 A/M to USB 3.0 A/M)
• Quick Setup Guide
SYSTEM REQUIREMENTS
• Computer with a USB port
• Windows® 10 (32-bit and 64-bit),
Mac OS 10.12 through 11.4,
Chrome OS 67 through 90
FEATURES
• Supports USB 3.0, compatible with USB 2.0 and
USB 1.1
• USB 3.0 data transfer rate up to 5.0 Gbps
(maximum)
• Users can choose PC1 or PC2 by pressing the
switch button on the HUB
• Two LED indicators show which PC is connected:
• LED1 on, PC1 is connected,
PC2 disconnected, LED2 o
• LED2 on, PC2 is connected,
PC1 disconnected, LED1 o
• Plug&Play and hot plug are supported
Switch port features
• Upstream port:
• USB 3.0 AF (2 ports)(connect PC1 and PC2)
• USB-C port for optional power, no data transfer
function
• Downstream port:
USB 3.0 AF (4 ports)(connect peripheral devices:
ash drives, mouse, keyboard, and hard drive)
• Switch button:
Changes the selected computer (PC1 or PC2)
Before using your new product, please read these instructions to prevent any damage.
QUICK SETUP GUIDE
4-Port
USB Switch
NS-PH3A4AS
LED 2 (PC2)
LED 1 (PC1)
Upstream USB 3.0
(to PC1)
USB-C
(DC in)
Upstream USB 3.0
(to PC2)
Switch button
Downstream USB 3.0
(to devices)
OVERVIEW
Front Back
V1 ENGLISH 21-0434
USING YOUR HUB
1 Connect the USB power cable to the hub and
plug it in to a power outlet.
2 Connect the switch downstream ports to
devices like ash drives, mouse, keyboard, or
external hard drive.
3 Connect the switch upstream ports to PC1 and PC2
with the USB 3.0 cables (included).
Note: If two devices are connected, PC1 is initially selected
and LED 1 is on. PC2 is not connected and LED 2 is o.
If only one device is connected, use the PC1 connection.
4 To select PC2, press the switch button. PC2 is
selected and LED 2 turns on and PC1 is
disconnected and LED 1 turns o.
Note: Properly eject USB ash drives and USB hard drives
before clicking the switch button to prevent corrupting
your data.
SPECIFICATIONS
• Dimensions: 3.9 × 2 × .6 in. (10.1 × 5.2 × 1.65 cm)
• Transmission port: USB 3.0
• Work temperature: 32° F ~ +122° F (0° C ~ +50° C)
• Work humidity: 20% RH ~ 85% RH
• USB 3.0 cable length: 59 in. (1.5 m)
LEGAL NOTICES
FCC Caution
Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment o and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
ICES Statement
CAN ICES-003 (B) /NMB-003 (B)
Device 1
Flash drive
Device 2
Mouse
Device 3
External hard drive
Back
ONE-YEAR LIMITED WARRANTY
Visit www.insigniaproducts.com for details.
CONTACT INSIGNIA
For customer service, call
1-877-467-4289 (U.S. and Canada)
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its aliated companies.
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richeld, MN 55423 U.S.A.
©2021 Best Buy. All rights reserved.
Outlet
USB power cable
USB 3.0 cable
USB 3.0 cable
Front
PC1
PC2
