Sida 1/7
www.joy it.net-
Pascalstr. 8 47506 Neukirchen Vluyn-
LINE TRA
LINE TRA
LINE TRA
LINE TRALINE TRACKER
CKER
CKER
CKERCKER
SEN KY033LT-
1. GENERAL INFORMATION
1. GENERAL INFORMATION
1. GENERAL INFORMATION
1. GENERAL INFORMATION1. GENERAL INFORMATION
Dear costumer,
thank you very much for choosing our product.
In following, we will introduce you to what to observe while starting up
and using this product.
Should you encounter any unexpected problems during use, please do
not hesitate to contact us
www.joy it.net-
Pascalstr. 8 47506 Neukirchen Vluyn-
2. PIN ASSIGNMENT
2. PIN ASSIGNMENT
2. PIN ASSIGNMENT
2. PIN ASSIGNMENT2. PIN ASSIGNMENT
1. Connection
3. USAGE WITH A RASPBERRY PI
3. USAGE WITH A RASPBERRY PI
3. USAGE WITH A RASPBERRY PI
3. USAGE WITH A RASPBERRY PI3. USAGE WITH A RASPBERRY PI
KY033
KY033
KY033
KY033KY033 Raspberry Pi
Raspberry Pi
Raspberry Pi
Raspberry PiRaspberry Pi
GND Ground
(Pin 6)
V+ 3,3 V
(Pin 1)
Signal GPIO24
(Pin 18)
www.joy it.net-
Pascalstr. 8 47506 Neukirchen Vluyn-
2. Code example
This sample code shows in the console whether the sensor is above a line
or not. This is done by infrared, because if the sensor is on the line, the
transmitted infrared signal does not reach the receiver.
# Required modules are imported and set up
import as RPi.GPIO GPIO
import time
GPIO.setmode(GPIO.BCM)
# The input pin to which the sensor is connected, is declared here.
GPIO_PIN = 24
GPIO.setup(GPIO_PIN, GPIO.IN, pull_up_down = GPIO.PUD_UP)
# Pause between the output of the result is defined (in seconds)
delayTime = 0.5
print ("Sensor Test [druecken Sie STRG+C, um den Test zu beenden]")-
# Main loop of the program
try:
while True:
if GPIO.input(GPIO_PIN) == True:
print ("LineTracker is above the line")
else:
print ("LineTracker is out of a line")
print (" ")---------------------------------------
# Reset + Delay
time.sleep(delayTime)
# Clean up after the program has finished
except KeyboardInterrupt:
GPIO.cleanup()
You can also download this sample code .
here
here
here
herehere
Furthermore, the sensor has a potentiometer with which the
sensitivity can be adjusted. A LED also lights up when the sensor receives
an infrared signal, i.e. leaves the line.
But first you have to install this package:
sudo apt install python3 rpi.gpio-
Now, you can either use the following commands to download and unzip
the file :
wget http://sensorkit.joy- - it.net/images/c/cf/KY 033_RPi_Trackingsensor.zip
unzip KY-033_RPi_Trackingsensor.zip
