GENERALINFORMATION
DANGER
!!
ELECTRICSHOCKORFIREHAZARD
READALLWIRESIZING,VOLTAGEREQUIREMENTSANDSAFETY
DATATOAVOIDPROPERTYDAMAGEANDPERSONALINJURY
Generalinformation:
Thisthermostatisdesignedtoprovidethehighestlevelofaccuratetemperature
controlforresidentiallinevoltageelectricheatingin120or208/240volt.Almost
allelectricheatersinstalledasoriginalequipmentinaresidentialapplicationwill
be208or240volt.Itisveryrarethatahome,apartmentorcondominiumwould
bewiredwithall120voltheaters.Checkyourvoltagetomakesureyouhavethe
rightthermostatforyourheatervoltage.A2poleordoublewidecircuitbreakerat
thepanelwouldindicatethatyoushouldusethe240voltmodel.Asinglepoleor
singlewidebreakerwouldindicatea120voltcircuit.Therearesomeexceptions
tothisrulesocheckingwithavoltmeteristheonlywaytoknowforsure.Besafe
andsmart,electricitycancausesevereinjuryordeath.
Thethermostatwillprovideyearsofcomfortcontrolforyourfamilyforsmallfan
drivenelectricheaters,baseboards,radiantceiling,wallpanelheaters,cove
heaters,oranylinevoltageresistanceheatingsystemsthatdonothavean
electricmotorover1/3hp.Thethermostatwillbewarmtothetouchontop.This
theelectronicsoperating,italsoprovidesaircurrentsacrossthefaceofthe
thermostatthathelpitsenseroomtemperaturebetter.
Operation:
Thisprecisionelectronicthermostatwillsensetheroomairatthebottomofthethermostatbyathermistor.Thisverysensitivesensorwillsend
informationtothemicroprocessor.Asthetemperaturedrops,theinformationitsendswillindicateifheatisneeded.Toreduceanyundesirablefast
on/offcycles,theprocessorhasabuiltin1to3minutedelay.Thiswillsaveenergyandprovidethebestcontrolofaspace.Thisthermostatdosenot
requirebatteriesandwillhaveadefaultsettingof68°Fwhenpoweredup.Itiseasilychangedbytappingthearrowkeysonthefrontofthe
thermostat.Uparrowincreasestemperatureanddownarrowreducestemperature.Backlightingisprovidedonsomemodelsandcanbeturnedoff
oronbyasmallswitchundertheleftcornerofthethermostat.Thiswillallowyoutoseethethermostatinlowlightoratnight.
Installation:
Thislinevoltagedeviceshouldbeinstalledandservicedbyaqualifiedelectrician.Thethermostathasbeendesignedtomounttoastandard2”x4”
electricaloutletbox.Levelingofthethermostatisnotrequired.Mountingscrewsareprovided.Mountthethermostataboutfivefeetabovethefloor
inanopenareainthelivingroom.Agoodruleofthumbistoplacethethermostatabovethewallswitchforthatroom.Thisworkswellformost
bedroomandmakesitveryconvenienttoturntheheatlowerwhenleavingtheroom.Avoidmountingthethermostatwheretheremaybeplumbing
pipesinthewallorplacingalamporTVtooclosetothethermostat.Theheatfromtheseitemsaffectsthethermostatsperformance.
ES-230&ES-120
DISPLAYLEGEND
RESET(UNDERCOVER)
SETPOINTDISPLAY
ROOMTEMPERATUREDISPLAY
TEMPERATUREUPANDDOWN
HEATINGINDICATOR
BACKLIGHTSWITCH
Specifications:ForES-120andES-230
Temperaturerange:40to95
TemperatureDefault:68Degrees
DisplayFormat:LiquidCrystalDisplay(LCD)
DisplaySize:ExtraLargeFormat-2"x1½"
SampleRate:Every60seconds
TimeDelay:3Minutesonandoff
Relayrating:30ampsbeforeDe-rating
Backlighting:LED
HeatIndicator:RedLED
Accuracy:+or-1.2DegreesF
Rating:22ampsresistivecontinues
Wattage:5280wattsES-230
2640wattsES-120
PowerSupply:120voltforES-120
208/240voltforES-230
SAVETHESEINSTRUCTIONS
TEMPERATURESENSOR
KINGELECTRICALMFG.CO.913110THAVENUESOUTHSEATTLE,WA98108·PH:206.762.0400·FAX:206.763.7738·www.king-electric.com1
ESPInstructions110.06.04.ai
