Kramer VP-108 Bruksanvisning
Läs nedan 📖 manual på svenska för Kramer VP-108 (18 sidor) i kategorin mottagare. Denna guide var användbar för 9 personer och betygsatt med 3.9 stjärnor i genomsnitt av 5 användare
Sida 1/18
Kramer Electronics, Ltd.
USER MANUAL
Model:
VP-108
1:8 XGA / Balanced Stereo Audio DA
Contents
i
Contents
1
Introduction 1
2
Getting Started 1
2.1
Quick Start 1
3
Overview 3
4
Your VP-108 1:8 XGA / Balanced Stereo Audio DA 3
5
Installing the VP-108 in a Rack 6
6
Connecting the VP-108 1:8 XGA / Balanced Stereo Audio DA 7
6.1
Connecting the Balanced/Unbalanced Stereo Audio Input/Output 9
6.2
Controlling via RS-232 (for example, using a PC) 8
6.2.1
Setting the Dipswitches 8
6.2.2
Setting the MACHINE # 9
6.3
Connecting the REMOTE Connector 9
7
Technical Specifications 11
8
Table of Hex Codes for Serial Communication 12
Figures
Figure 1: VP-108 1:8 XGA / Balanced Stereo Audio DA 4
Figure 2: VP-108 Underside 5
Figure 3: Connecting the VP-108 1:8 XGA / Balanced Stereo Audio DA 8
Figure 4: Connecting the Balanced Stereo Audio Input/Output 9
Figure 5: Connecting the Unbalanced Stereo Audio Output 9
Figure 6: Connecting an Unbalanced Source to the Balanced VP-108 Input 9
Figure 7: Connecting a VP-108 Unit to a PC without using a Null-modem Adapter 8
Figure 8: SETUP Dipswitches 8
Figure 9: REMOTE Terminal Block Connector 10
Tables
Table 1: VP-108 1:8 XGA / Balanced Stereo Audio DA Features 5
Table 2: VP-108 Underside Features 5
Table 3: Dipswitch Settings 8
Table 4: Machine # Dipswitch Settings 9
Table 5: Technical Specifications of the VP-108 1:8 XGA / Balanced Stereo Audio DA 11
Table 6: VP-108 Hex Codes 12
Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range
of problems that confront the video, audio, presentation, and broadcasting
professional on a daily basis. In recent years, we have redesigned and upgraded
most of our line, making the best even better! Our 1,000-plus different models
now appear in 11 groups
1
that are clearly defined by function.
Congratulations on purchasing your Kramer VP-108 1:8 XGA / Balanced
Stereo Audio DA (distribution amplifier) which is ideal for using with ,
presentation systems, and video duplication and production studios.
The package includes the following items:
VP-108 1:8 XGA / Balanced Stereo Audio DA
Power cord
Windows®-based Kramer control software
Null-modem adapter
This user manual
2
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
Use Kramer high performance high resolution cables
3
2.1 Quick Start
This quick start chart summarizes the basic steps when connecting a : VP-108
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems; GROUP 4:
Format/Standards Converters; GROUP 5: Twisted-Pair Solutions; GROUP 6: Specialty AV Products; GROUP 7: Scan
Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and
Rack Adapters; GROUP 11: Sierra Products
2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com
3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com
