Sida 1/15

Kramer Electronics, Ltd.

USER MANUAL

Model:

VP-12NHD

1:12 + 3 UXGA / CAT5 Distributor

Contents

Introduction 1

Getting Started 1

2.1

Quick Start 1

Overview 3

3.1

About the Power Connect Feature 3

3.2

Shielded Twisted Pair (STP) / Unshielded Twisted Pair (UTP) 3

3.3

About the VP-12NHD 3

3.4

Recommendations for Achieving the Best Performance 4

Your VP-12NHD 1:12 + 3 UXGA / CAT5 Distributor 4

Installing on a Rack 7

Using Your VP-12NHD 1:12 + 3 UXGA / CAT5 Distributor 8

6.1

Wiring the CAT5 LINE IN / LINE OUT RJ-45 Connectors 10

Technical Specifications 11

Figures

Figure 1: VP-12NHD 1:12 + 3 UXGA / CAT5 Distributor 5

Figure 2: Underside of the VP-12NHD 1:12 + 3 UXGA / CAT5 Distributor 5

Figure 3: Connecting the VP-12NHD 1:12 + 3 UXGA / CAT5 Distributor 9

Figure 4: CAT5 PINOUT 10

Tables

Table 1: Front and Rear Panel Features of the VP-12NHD 6

Table 2: Underside Features of the VP-12NHD 6

Table 3: CAT5 PINOUT 10

Table 4: Technical Specifications of the VP-12NHD 1:12 + 3 UXGA / CAT5 Distributor 11

Introduction

1 Introduction

Welcome to Kramer Electronics (since 1981): a world of unique, creative and

affordable solutions to the infinite range of problems that confront the video,

audio and presentation professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

500-plus different models now appear in 8 Groups

, which are clearly defined

by function.

Congratulations on purchasing your Kramer VP-12NHD 1:12 + 3 UXGA /

CAT5 Distributor, which is ideal for:

 Presentation and multimedia applications that require high quality

computer graphics distribution to multiple monitors and/or projectors

 Long range graphics distribution for schools, hospitals, security, and stores

The package includes the following items:

 VP-12NHD 1:12 + 3 UXGA / CAT5 Distributor

 Power cord

 This user manual

2 Getting Started

We recommend that you:

 Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

 Review the contents of this user manual

 Use Kramer high performance high resolution cables

2.1 Quick Start

This quick start chart summarizes the basic setup and operation:

1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:

Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;

GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors

2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

Produktspecifikationer

Varumärke:	Kramer
Kategori:	mottagare
Modell:	VP-12NHD
Vikt:	2700 g
Bredd:	482.6 mm
Djup:	177.8 mm
Höjd:	25.4 mm
VGA (D-Sub) ingångsportar:	1
Bandbredd:	330 MHz
RJ-45 utgångsportar:	3
Spänning:	230 V
VGA (D-Sub) utgångsportar:	12
Växelström Frekvens:	50 - 60 hz
K-faktor:	0.05 %
Signal/brusförhållande (SNR):	73 dB
Differentiell fas:	0.44 °
Differentiell förstärkning:	0.17 %
Maximal utgångsnivå:	1.7 Vpp
