Kramer Electronics, Ltd.

USER MANUAL

Models:

VP-3xl,

1:3 VGA/UXGA Distributor

VP-4xl,

1:4 VGA/UXGA Distributor

VP-5xl,

1:5 VGA/UXGA Distributor

Contents

Introduction 1

Getting Started 1

Overview 1

Your VGA/UXGA Distributor 2

4.1

Your VP-3xl 1:3 VGA/UXGA Distributor 3

4.2

Your VP-4xl 1:4 VGA/UXGA Distributor 4

4.3

Your VP-5xl 1:5 VGA/UXGA Distributor 5

4.4

Your VP-3xl, VP-4xl, and VP-5xl VGA/UXGA Distributor Underside 6

Using Your VGA/UXGA Distributor 6

Technical Specifications 7

Figures

Figure 1: VP-3xl 1:3 VGA/UXGA Distributor 3

Figure 2: VP-4xl 1:4 VGA/UXGA Distributor 4

Figure 3: VP-5xl 1:5 VGA/UXGA Distributor 5

Figure 4: VGA/UXGA Distributor Underside 6

Figure 5: Connecting the VP-5xl to 5 Monitors 7

Tables

Table 1: Front Panel VP-3xl 1:3 VGA/UXGA Distributor Features 3

Table 2: Rear Panel VP-3xl 1:3 VGA/UXGA Distributor Features 3

Table 3: Front Panel VP-4xl 1:4 VGA/UXGA Distributor Features 4

Table 4: Rear Panel VP-4xl 1:4 VGA/UXGA Distributor Features 4

Table 5: Front Panel VP-5xl 1:5 VGA/UXGA Distributor Features 5

Table 6: Rear Panel VP-5xl 1:5 VGA/UXGA Distributor Features 5

Table 7: VGA/UXGA Distributor Underside Features 6

Table 8: Technical Specifications of the VP-3xl / VP-4xl / VP-5xl VGA/UXGA Distributor 7

Introduction

1 Introduction

Welcome to Kramer Electronics (since 1981): a world of unique, creative and

affordable solutions to the infinite range of problems that confront the video,

audio and presentation professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

350-plus different models now appear in 8 Groups

, which are clearly defined

by function.

Congratulations on purchasing your Kramer VP-3xl, VP-4xl, and/or VP-5xl,

which are ideal for:

 Any professional system requiring high quality VGA/UXGA distribution

to multiple monitors and/or projectors

 Larger distribution systems, made by easily cascading several machines

The package includes the following items:

 VP-3xl 1:3 VGA/UXGA Distributor, or VP-4xl 1:4 VGA/UXGA

Distributor, or VP-5xl 1:5 VGA/UXGA Distributor

 Power cord

 This user manual

2 Getting Started

We recommend that you:

 Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

 Review the contents of this user manual

 Use Kramer high performance high resolution cables

3 Overview

The high performance Kramer VP-3xl, VP-4xl, and VP-5xl are three

distribution amplifiers (1:3, 1:4, and 1:5) for VGA/UXGA signals. Each

machine:

1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:

Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;

GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors

2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com/manuals.html

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com (click “Cables and Connectors”

in the Products section)

Produktspecifikationer

Varumärke:	Kramer
Kategori:	mottagare
Modell:	VP-3XL
Vikt:	1200 g
Bredd:	220 mm
Djup:	180 mm
Höjd:	45 mm
VGA (D-Sub) ingångsportar:	1
Bandbredd:	375 MHz
Spänning:	100-240 V
VGA (D-Sub) utgångsportar:	3
Växelström Frekvens:	50 - 60 hz
K-faktor:	0.05 %
Signal/brusförhållande (SNR):	73.7 dB
Differentiell fas:	0.28 °
Differentiell förstärkning:	0.12 %
Maximal utgångsnivå:	1.9 Vpp
