P/N: 2900-301241 Rev 1 www.kramerAV.com
USER MANUAL
MODEL:
VP-429H2
Automatic Video Switcher / Scaler
Kramer Electronics Ltd.
VP-429H2 Contents
i
Contents
Introduction 1
Getting Started 1
Overview 2
Typical Applications 3
Defining VP-429H2 Automatic Video Switcher / Scaler 4
Mounting VP-429H2 6
Connecting VP-429H2 7
Connecting to VP-429H2 via RS-232 8
Setting the DIP-Switches 9
Connecting the Remote Control Switches 9
Operating and Controlling VP-429H2 10
Selecting an Input 10
Auto Adjusting the VGA Signal 11
Adjusting the Output Volume 11
Performing a Step-in Operation 11
Operating via Ethernet 12
Using the Embedded Web Pages 15
Browsing VP-429H2 Web Pages 16
Switching the Inputs and Adjusting the Signal 17
Changing Device Settings 18
Triggering Commands via the DATA RS-232 Port 19
Defining Video and Audio Settings 21
Setting Web Page Access Permission 23
Managing EDID 25
Upgrading the Firmware 29
Viewing the About Page 30
Upgrading the Firmware via USB Port 31
Technical Specifications 32
Supported Input Resolutions 33
Supported Output Resolutions 34
Default Communication Parameters 35
Default EDID 35
Protocol 3000 38
Understanding Protocol 3000 38
Protocol 3000 Commands 39
Result and Error Codes 47
Kramer Electronics Ltd.
VP-429H2 Introduction
1
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and affordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we
have redesigned and upgraded most of our line, making the best even better!
Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.
Review the contents of this user manual.
Go to www.kramerav.com/downloads/VP-429H2 to check for up-to-date user manuals,
application programs, and to check if firmware upgrades are available (where appropriate).
Achieving the Best Performance
Use only good quality connection cables (we recommend Kramer high-performance,
high-resolution cables) to avoid interference, deterioration in signal quality due to poor
matching, and elevated noise levels (often associated with low quality cables).
Do not secure the cables in tight bundles or roll the slack into tight coils.
Avoid interference from neighboring electrical appliances that may adversely influence
signal quality.
Position your Kramer VP-429H2 away from moisture, excessive sunlight and dust.
Safety Instructions
Caution:
This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.
For products with relay terminals and GPI\O ports, please refer to the permitted rating
for an external connection, located next to the terminal or in the User Manual.
There are no operator serviceable parts inside the unit.
Warning:
Use only the power cord that is supplied with the unit.
To ensure continuous risk protection, replace fuses only according to the rating
specified on the product label which located on the bottom of the unit.
