Kramer VS-42H2 Bruksanvisning
Läs gratis den bruksanvisning för Kramer VS-42H2 (3 sidor) i kategorin Router. Guiden har ansetts hjälpsam av 17 personer och har ett genomsnittsbetyg på 4.4 stjärnor baserat på 9 recensioner. Har du en fråga om Kramer VS-42H2 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga
Sida 1/3
Kramer Electronics Ltd.
VS-42H2 – Contents
i
Contents
Introduction 1
Getting Started 1
Overview 2
Typical Applications 3
Defining VS-42H2 4K 4x2 HDMI Matrix Switcher 4
Mounting VS-42H2 6
Connecting VS-42H2 7
Connecting to VS-42H2 via Ethernet 8
Connecting the Remote Input Selection Switches 10
Connecting to VS-42H2 via RS-232 10
Operating and Controlling VS-42H2 via Front Panel Buttons 11
Locking and Unlocking Front Panel Buttons 11
Acquiring an EDID from an Output 11
Muting and Unmuting Output AV 12
Routing an Input to an Output 12
Configuring and Maintaining VS-42H2 13
Setting DIP-Switches 13
Resetting VS-42H2 to Factory Default Settings 14
Upgrading Firmware 14
Using Embedded Web Pages 15
Routing and Setting the Inputs and Outputs 16
Managing EDID 18
Setting Device Parameters 20
Upgrade the Firmware 22
Viewing the About Us Page 23
Technical Specifications 24
Default Communication Parameters 25
Default EDID 25
Protocol 3000 28
Understanding Protocol 3000 28
Protocol 3000 Commands 29
Result and Error Codes 35
Kramer Electronics Ltd.
VS-42H2 – Introduction
1
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and affordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we
have redesigned and upgraded most of our line, making the best even better!
Getting Started
We recommend that you:
• Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.
• Review the contents of this user manual.
Go to www.kramerav.com/downloads/VS-42H2 to check for up-to-date user manuals,
application programs, and to check if firmware upgrades are available (where appropriate).
Achieving Best Performance
• Use only good quality connection cables (we recommend Kramer high-performance,
high-resolution cables) to avoid interference, deterioration in signal quality due to poor
matching, and elevated noise levels (often associated with low quality cables).
• Do not secure the cables in tight bundles or roll the slack into tight coils.
• Avoid interference from neighboring electrical appliances that may adversely influence
signal quality.
• Position your Kramer VS-42H2 away from moisture, excessive sunlight and dust.
Safety Instructions
Caution:
• This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.
• For products with relay terminals and GPI\O ports, please refer to the permitted rating
for an external connection, located next to the terminal or in the User Manual.
• There are no operator serviceable parts inside the unit.
Warning:
• Use only the power cord that is supplied with the unit.
• To ensure continuous risk protection, replace fuses only according to the rating
specified on the product label which located on the bottom of the unit.
