LEICA MONOVID 20 8x

Anleitung

Instructions

Notice d’utilisation

Gebruiksaanwijzing

Istruzioni

Instrucciones

取扱説明書

Leica Camera AG

Oskar-Barnack-Straße 11

35606 SOLMS

DEUTSCHLAND

Telefon +49 (0) 6442-208-0

Telefax +49 (0) 6442-208-333

www.leica-camera.com

93 304 VI/09/DX/B

english

CONTENTS

Foreword 6 ��

Items supplied 6 ��

Designation of parts 6 ��

Attaching the carrying strap and

the eyepiece protective cap 8 ��

Adjusting the eye cups/

Using with and without glasses 8 ��

Adjusting the focus 8 ��

Using the close up lens 8 ��

Care/cleaning 9 ��

Spare parts 9 ��

Technical data 10 ��

Leica on the Internet and Leica Academy 11 ��

Leica Information Service 11 ��

Leica Customer Care 11 ��

WARNING INFORMATION

• Never look at the sun or other bright light sources

through the monocular� This can cause injury to

the eye�

• Never look through the monocular while walking.

You could miss obstructions�

attachIng the carryIng straP and

the eyePIece PrOtectIve caP

(See also Figure 1a/1b on the inside rear cover)

Note that the carrying strap has two loops:

– a shorter loop for attaching to the eyelet on the

monocular

– a longer loop for attaching the eyepiece protective cap

adjustIng the eye cuP/

usIng WIth and WIthOut glasses

The eyepiece eye cup (1) is adjustable� It should be

extended (1a) for viewing without and retracted for view-

ing with glasses (1b)�

adjustIng the fOcus

The focus is adjusted for objects at diﬀerent distances

using the focusing ring (3)�

usIng the clOse uP lens

The LEICA MONOVID 8x20 can also be used to provide a

magniﬁed view of objects that are at close range�

To do this, the close up lens (5) supplied is screwed into

the inner thread (5a) on the monocular lens (clockwise)�

Depending on the position of the focusing ring, this

results in a viewing distance of around 25–30cm with an

identical magniﬁcation�

Produktspecifikationer

Varumärke:	Leica
Kategori:	Kikare
Modell:	Monovid 8 x 20
Vikt:	112 g
Bredd:	35.5 mm
Djup:	97.9 mm
Höjd:	35.5 mm
Elektronisk kompass:	Nej
Vattentät:	Ja
Vattentät upp till:	5 m
Förstoring:	7 x
Synfält:	110 m
Prismor:	Takprisma
Objektivlins diameter:	20 mm
Utgångspupill:	2.5 mm
Twilight faktor:	12.7
Ögonmussla:	15 mm
Närmsta fokusavstånd:	1.5 m
Synligt bildfält:	6.3 °
