Luxe Inset Sinks Fitting Instructions
1. It is recommended that the Inset sink is tted to the
worktop before being permanently xed to the cabi-
net.
2. Place the sink upside down on worktop. Position the
sink relative to the worktop as required, ensuring that
the cabinet framework will be clear of all parts of the
sink.
With sharp soft pencil draw round sink as accurately
as possible. See g. 1.
3. Remove the sink and draw another line 10mm inside
the outline of the sink top following the corner radii
with care. This is the cutting line for the aperture.
Fig. 1
Fig. 3
4. Drill as large a hole as possible inside the cutting line.
Using a pad saw, jig saw or similar, cut out the aperture
to the cutting line.
5. Remove paper backing from the foam tape and stick
down to the worktop, lining up the inner edge of the
tape 3 to 4mm from the edge of the cut, see g. 2. A
neat butt joint of the two ends is desirable. The tape
may be stretched slightly to obtain this. The worktop
should be clean and dry before application.
6. Attach the xing clips to the sink rail as shown in
g. 3 ensuring that the two ‘prongs’ of the clip face
inwards.
Open the hinge on the clip.
7. Turn the sink upside down and lay the worktop over
the sink. Swing the clip into position. (This is the most
eective method although if the worktop has been
xed to the cabinet, the sink can be placed in the
aperture and the xing eected from underneath).
8. With the sink secured in position the excess sealing
tape should be cut o by carefully running a sharp
knife or razor blade round the periphery of the sink
and then lifting the excess tape away.
Fig. 2
NB The adjustment of the clamping bracket for U.K. mar-
ket suits worktops of thicknesses 27mm to 43mm.
Any variations from these thicknesses will either
require packing under the clips or for the worktops
to be rebated.
Recommended tightening sequence for sink xing
clips
Produktspecifikationer
| Varumärke: | Leisure |
| Kategori: | Sjunka |
| Modell: | LX84 |
| Bredd: | 2120 mm |
| Djup: | 460 mm |
| Produktens färg: | Rostfritt stål |
| Typ av diskho: | Toppmonterat handfat |
| Diskhons form: | Rektangulär |
| Diskhons material: | Rostfritt stål |
| Antal diskhoar: | 2 hoar |
| Första diskhons form: | Rektangulär |
| Första skål mått (BxL): | 420 x 350 mm |
| Första skål djup: | 190 mm |
| Andra diskhons form: | Rektangulär |
| Andra skålen mått (BxL): | 420 x 350 mm |
| Andra skålen djup: | 190 mm |
| Hål för kran: | Ja |
| Antal hål för kranar: | 1 |
| Diskställ: | Ja |
| Faucet ingår: | Nej |
| Tryck hålstorlek: | 35 mm |
